Shop TE CONNECTIVITY

SOCKET MIN-SPR SN-AU SER-5

  • Mfr # 5050871-5

  • Zoro # G301026560

product price:  $1.25
/ea
Sold in multiples of 105 for $131.25

Key Features

Insertion Method
Hand/Semi-Automatic
Termination Method to Wire & Cable
Solder
Wire/Cable Type
Discrete Wire
Contact Spring Plating Material
Gold
Termination Method to Printed Circuit Board
Through Hole - Press-Fit
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
5050871-5
Zoro #
G301026560
UPC #
-
Country of Origin
United States

Dimensions

Wire/Cable Size
18 to 17 AWG
Contact Spring Plating Thickness
30 µin
PCB Thickness (Recommended)
.031 to .125 in
Socket Length
.288 in
Mating Pin Diameter Range
.042 to .049 in
Hole Size (Recommended)
.101 in
Contact Mating Area Plating Thickness
30 µin

Details

Insertion Method
Hand/Semi-Automatic
Termination Method to Wire & Cable
Solder
Wire/Cable Type
Discrete Wire
Contact Spring Plating Material
Gold
Termination Method to Printed Circuit Board
Through Hole - Press-Fit
Connector & Contact Terminates To
Printed Circuit Board
Contact Current Rating (Max)
7.5 A
Sleeve Style
Closed Bottom
Sleeve Material
Copper
Spring Material
Beryllium Copper
Contact Type
Socket
Socket Type
Discrete
Connector System
Cable-to-Board
Circuit Application
Power & Signal
Sleeve Plating Material
Tin
Operating Temperature Range
-65 to 125 °C
Contact Base Material
Beryllium Copper
Contact Transmits (Typical)
Signal (Data)/Power
Profile
Zero
Product Type
Contact
