Socket, Power Relay, 0.3 A, Plug-in
Mfr # 1-1393102-9
Zoro # G205866033
product price:Â $73.99
/eaKey Features
Mounting Style
Panel Mount / Plug In
Electrical Connection
Pins
Coil Voltage
24V DC
Current Rating
10 A
Features
UL Coil Insulation Class B
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 1-1393102-9
- Zoro #
- G205866033
- UPC #
- -
- Country of Origin
- Mexico
Details
- Item
- General Purpose Relay
- Mounting Style
- Panel Mount / Plug In
- Electrical Connection
- Pins
- Coil Voltage
- 24V DC
- Current Rating
- 10 A
- Features
- UL Coil Insulation Class B
- Contact Material
- AgCdO
- Number of Poles
- 1
- Power Consumption - Relay
- 1250 mW
- Contact Voltage Rating
- 240 VAC
- Switching Current
- 300mA @ 12V
- Coil Resistance
- 472 Ω
- Operating Temp. Range
- -45 to 70°C
- Protection Category
- RTI
- Contact Rating
- 0.416666666666667A
- Dielectric Voltage
- 1000 Vrms Adjacent Contacts; 1000 V, 1000 Vrms Coil and Contact; 1000 Vrms Open Contacts
- Coil Type
- Monostable, DC
- Base Shape
- Octal
- Number of Pins
- 8
- Contact Rating (AC)
- 10 A @ 240V
- Contact Form
- SPDT
Description
Power/Signal Relay, Spdt, Momentary, 0.05A (Coil), 24Vdc (Coil), 1200Mw (Coil), 10A (Contact), Dc Input, Ac/Dc Output, Socket Mount
