Product Information
MFR #
1-1986374-0
Zoro #
G400945526
UPC #
-
Country of Origin
Italy
Dimensions
Screw Size
M2
Details
Housing Color
Green
Housing Material
PA 6.6
Side Stackable
Yes
Applies To
Wire/Cable
Contact Base Material
Phosphor Bronze
Wire Entry Angle
Side
Number of Positions
10
Block Type
None
Wire Range
.05 to 2 mm² [ 30 to 14 AWG ]
Connector Style
Plug
Screw Flange
Without
Interlock
Without
Screwless Terminal Block
No
Current Rating (Max) (A)
11
Centerline
3.81 mm [ .1499 in ]
Mounting Angle
Vertical
Screw Material
Brass
Voltage (VAC)
300
Screw Plating Material
Nickel
Contact Mating Area Plating Material
Tin
Number of Rows
1
