Product Information
MFR #
1558666-7
Zoro #
G001033622
UPC #
-
Country of Origin
Portugal
Dimensions
Dimensions
1.142 x 0.846 x 0.618 in
Details
Item
Power Relay
Mounting Style
PCB
Electrical Connection
Printed Circuit Terminals
Coil Voltage
24V DC
Contact Form
1 Form A (NO)
Features
UL Coil Insulation Class F
Power Consumption - Relay
900 mW
Contact Material
AgSnO
Number of Poles
1
Coil Type
Monostable, DC
Dielectric Voltage
2500 Vrms Coil and Contact; 4000 Vrms Open Contacts
Contact Voltage Rating
250 VAC
Contact Rating
30 A
Switching Current
1A @ 12V
Operating Temp. Range
-40 to 105°C
Coil Resistance
640 Ω
Protection Category
RTIII
Switching Voltage
480 VAC
