Contact our U.S. based teamSpecifications
Product Information
MFR #
282830-8
Zoro #
G600929869
UPC #
-
Country of Origin
Italy
Dimensions
Screw Size
M3
Details
Voltage
300 VAC
Wire Range
30 to 12 AWG
Number of Rows
1
Centerline (Pitch)
.197 in
Mating Angle
90°(Bottom)/ 180° (Side)
Housing Material
Polyamide 6.6 GF
Side Stackable
No
Marking Color
Black
Screw Flange
Without
Contact Mating Area Plating Material
Tin
Wire Entry Angle
Side
Screw Plating Material
Nickel
Block Type
Special Plug
Screw Material
Brass
Housing Color
Green
Contact Base Material
Phosphor Bronze
Current Rating (Max)
12A
Interlock
Without
Screwless Terminal Block
Yes
Number of Positions
8
Connector Style
Plug
Connector & Contact Terminates To
Wire & Cable
Mounting Angle
Right Angle, Vertical
