Tap Holder, Straight, ER11, 1.043in, Steel

  • Mfr # 04891
  • Zoro # G9406327
product price:
$
156.99
/ea
Free Shipping & Returns

Key Features

Collet Series
ER11
For Use With
Collet Chuck Tool Holders
Nut Dia.
0.630 in
Max. Collet Capacity
0.250 in
Dimension Type
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
04891
Zoro #
G9406327
UPC #
-
Country of Origin
Taiwan, Province of China
Item
Collet Chuck Extension
Collet Series
ER11
For Use With
Collet Chuck Tool Holders
Max. Collet Capacity
0.250 in
Projection
26.50 mm
Min. Collet Capacity
0.0200 in
Material
Steel
Shank Type
Straight
Coolant Fed
Coolant Through
Features
Balanced Up to 25,000 RPM
Coolant Supply
Coolant Through
Compatible Collet Wrench
04621
Included Nut Type
Mini
T.I.R. Tolerance
0 in
Compatible Collet Series
ER11
Compatible Product Type
ER Collets
Compatible Nut Model Number
23111
Speed - Maximum
25,000 RPM

Dimensions

Nut Dia.
0.630 in
Dimension Type
Straight
Overall Length
166.5 mm
Shank Dia.
1/2 in
Nose Dia.
16.00 mm
Shank Diameter
1/2 in
Shank Length
140 mm
Head Length
26.5 mm
Head Diameter
16 mm
Wire Rope Length
166.5 mm
Length
166.5 mm

Description

Tap Holder, Dimension Type Straight, Collet Series ER11, Min. Collet Capacity 0.0200 In., Max. Collet Capacity 0.2500 In., Projection 1.043 In., Nut Dia. 0.630 In., Material Steel, For Use With Collet Chuck Tool Holders
