  11. Tool Holder, 6-11/16in L, 1.0in. dia.
Techniks Tool Holder, 6-11/16in L, 1.0in. dia. 22945-2.62 - main

Tool Holder, 6-11/16in L, 1.0in. dia.

  • Mfr # 22945-2.62

  • Zoro # G9407203

product price: $175.99
/ea
Free Shipping & Returns

Key Features

Type
V-Flange
Dimension Type
Decimal Inch
Projection
2.62 in
Application
For Holding Tools
Bore Dia.
1 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
22945-2.62
Zoro #
G9407203
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimension Type
Decimal Inch
Bore Dia.
1 in
Socket Depth (In.)
1.18
Hole Dia.
1.0"
Overall Length (In.)
6-11/16
Taper Size
CAT50
Dia.
2.0"
Nose Dia.
2 in
Overall Diameter
3 7/8 in
Bore Diameter
1 in
Body Width
2.75 in
Nose Diameter
2 in
Body Diameter
2.75 in

Details

Type
V-Flange
Projection
2.62 in
Application
For Holding Tools
Taper
CAT50
Series
SLN
For Use With
End Mill Cutter
Thread
3/4-16
End
Single
Item
End Mill Holder
Standards
DIN 69871-AD
End Type
Single End
Measurement System
Inch
Shank Type - Machining
Taper
Features
Balanced to 15,000 RPM @ G6.3, Improved T.I.R. for extended Cutting Tool Life, Tapered body design Reduces Vibration and Enhances Rigidity, Increased Rigidity and Accuracy during Heavy Side Loads
Speed - Maximum
15,000 RPM
T.I.R. Tolerance
0.0002 in
Coolant Supply
Coolant Through-Spindle
Balance Rating
G6.3
Bore Tolerance
H5
Contact Type
Single Contact
Product Type
End Mill Holder

Description

End Mill Holder, Taper Size CAT50, Bore Dia. 1 in, Projection 2.62 in, Nose Dia. 2 in, Measurement System Inch, End Type Single End
