  15. 2NC/1NO Safety Interlock Switch IP 67
Telemecanique Sensors 2NC/1NO Safety Interlock Switch IP 67 XCSLF3737533 - main

2NC/1NO Safety Interlock Switch IP 67

  • Mfr # XCSLF3737533

  • Zoro # G4404005

product price: $755.99
/ea
Free Shipping & Returns

Key Features

Style
Metal Locking with Power
Series
XCSLF
AC Contact Rating
0.75 A @ 240 V
Solenoid Voltage
120 V AC
Contact Form
1NO/2NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XCSLF3737533
Zoro #
G4404005
UPC #
785901981633
Country of Origin
Indonesia

Dimensions

Height
8.07 in
Width
1.71 in
Depth
2.01 in
Conduit Size
1/2 in NPT
Overall Depth
2.01 in
Manufacturer Warranty Length
18 mo
Overall Height
8.07 in
Overall Width
1.73 in

Details

Item
Safety Interlock Switch
Style
Metal Locking with Power
Series
XCSLF
AC Contact Rating
0.75 A @ 240 V
Solenoid Voltage
120 V AC
Contact Form
1NO/2NC
Connection Type
1/2 in NPT Conduit
IP Rating
IP66, IP67
Operating Temp. Range
-13 Degrees to 140 Degrees F
Description/Special Features
300 Solenoid Contacts
Standards
CSA C22.2 No 14, EN 1088/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, EN/IEC 62061, EN/ISO 13849-1, UL 508
Body Material
Zamak
Head Material
Zamak
Operating Force
4.5 lb Unlocked, 517 lb Locked
Features
300 Solenoid Contacts
Electrical Connection
1/2 in NPT Conduit
Material
metal
Head Type
key operated turret head
Vibration Resistance
5 gn 10-500 Hz)IEC 60068-2-6
Mechanical Durability
1000000 cycles
Shock Resistance
10 gn 11 ms IEC 60068-2-27
Resistance Properties
Shock Resistant, Vibration Resistant
Actuating Key Type
Pivoting, Flat
Mechanical Operating Durability
1,000,000
Operating Temperature - Minimum
-13 Degrees F
Operating Temperature - Maximum
158 Degrees F
Actuator Material
Metal
Circuitry Action
Slow Action
Protective Treatment
TC
Contacts Type And Composition
2 NC + 1 NO
Component Name
XCSLF
[Ui] Rated Insulation Voltage
300 VUL 508 || 300 VCSA C22.2 No 14 || 250 V 3)EN/IEC 60947-1
Load Factor
1
[Ithe] Conventional Enclosed Thermal Current
4A
Solenoid Contacts Type And Composition
2 NC + 1 NO slow-break, break before make)
Safety Level
can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 EN/IEC 61508
Maximum Actuator Forcible Withdrawal Rtc
3000 N
Cable Entry
3 entries tapped 1/2" NPT
Product Certifications
TUV || CSA || UL
Electromagnet Interlocking
locking on energisation and unlocking on de-energisation of solenoid
Number Of Poles
3
Design
slim
[Us] Rated Supply Voltage
120 V - 15...10 %
[Ie] Rated Operational Current
0.55 A 24 V, DC-13, R300 EN/IEC 60947-5-1 || 0.75 A 240 V, AC-15, C300 EN/IEC 60947-5-1
Minimum Actuation Speed
0.01 m/s
Local Signalling
for actuator withdrawn 1 LED (orange) || for actuator inserted and locked 1 LED (green)
Contact Operation
slow-break, break before make
Product Or Component Type
safety switch
Ip Degree Of Protection
IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 || IP67
Minimum Switching Current
10 mA at 20°C
Maximum Actuation Speed
0.5 m/s
Minimum Actuator Force For Extraction
20 N
Minimum Switching Voltage
17 V
Positive Opening
with NC contact
Supply Voltage Type
AC/DC
Short-Circuit Protection
4 A cartridge fuse gG (gl) || 6 A fast blow
Signalling Circuit Type
AC
Maximum Operating Rate
10 cyc/mn for maximum durability
Ambient Air Temperature For Storage
-40-70°C
Resistance To Mechanical Impact
9.6 J against the partition || 6.4 J without partition
Supply Frequency
50/60 Hz
Maximum Load Current
<= 15 A
Signalling Circuit Voltage
120 V
Ambient Air Temperature For Operation
-25-60°C
Electrical Shock Protection Class
class I EN/IEC 61140
[Uimp] Rated Impulse Withstand Voltage
4 kV EN/IEC 60947-5-1

Description

Safety Interlock Switch, Metal Locking with Power, Contact Form 1NO/2NC, Connection Type 1/2 in NPT Conduit, AC Contact Rating 0.75 A @ 240 V, Series XCSLF, Solenoid Voltage 120 V AC, Height 8.07 in, Width 1.71 in, Depth 2.01 in, IP Rating IP66, IP67, Operating Temp. Range -13 Degrees to 140 Degrees F, Conduit Size 1/2 in NPT, Body Material Zamak, Head Material Zamak, Description/Special Features 300 Solenoid Contacts, Operating Force 4.5 lb Unlocked, 517 lb Locked
