  11. Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Brass, M12, 3 Wires, Shielded
Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Brass, M12, 3 Wires, Shielded XS112BLPBM12 - main

Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Brass, M12, 3 Wires, Shielded

  • Mfr # XS112BLPBM12

  • Zoro # G3478097

product price: $47.15
/ea

Key Features

Measurement Range
0 to 1.6 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 24V DC
Length
41 mm
Proximity Sensor Electrical Connection
4 Pin M12 Connector
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS112BLPBM12
Zoro #
G3478097
UPC #
785901480990
Country of Origin
Indonesia

Dimensions

Length
41 mm
Overall Diameter
12 mm
Overall Height
55 mm

Details

Item
Proximity Sensor
Measurement Range
0 to 1.6 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 24V DC
Proximity Sensor Electrical Connection
4 Pin M12 Connector
Proximity Sensor Operating Frequency
2,000 Hz
IP Rating
IP67
Description/Special Features
Overload And Short-Circuit Protection, Reverse Polarity, Yellow LED Output Indication
Standards
CE, CSA, RoHS, UL Listed
Operating Temp. Range
-13 Degrees to 158 Degrees F
Max. Current Load
100mA
Electrical Connection
M12
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Storage Temp. Range
-40-85 °C
Maximum Delay First Up
15 ms
Series
XS1
Maximum Delay Response
0.1 ms
Application
general purpose
Maximum Voltage Drop
<2 V closed)
Maximum Delay Recovery
0.15 ms
Body Type
fixed
Switching Capacity
<= 200 mA overload and short-circuit protection
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Differential Travel
1...15% of Sr
Supply Voltage Limits
10-36 V DC
Switching Frequency
2,500 Hz
AC Voltage Rating
Not Rated
DC Voltage Rating
12-24V DC
NEMA Enclosure Rating
4X
Operating Temperature - Maximum
158 Degrees F
Electrical Installation Type
Direct Connector
Number of Pins
4
Includes Indicator Lights
Indicator Lights Included
Sensing Distance - Maximum
2 mm
Style
Cylindrical, Inductive
Output Circuit Number of Wires
3
Output Circuit Type
PNP
Operating Temperature - Minimum
-13 Degrees F
Sensing Face Shielding
Shielded
Body Material
Brass
Load Current - Maximum
200 mA
Output Circuit Contact Form
NC
Body Finish
Nickel Plated

Description

Inductive Cylindrical Proximity Sensor, Inductive, 12 mm, Proximity Sensor Power Requirement 12 to 24V DC, Shielded, Proximity Sensor Operating Frequency 2,000 Hz, Proximity Sensor Output Circuit Type 3 Wire PNP, Max. Detecting Distance 2 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NC, NEMA Rating 4X, IP Rating IP67, Case Material Nickel Plated Brass, Length 41 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 100mA
