  6. Cylindrical, Inductive Proximity Sensor, 13 mm Dia., Stainless Steel, M8, 3 Wires, Shielded
Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 13 mm Dia., Stainless Steel, M8, 3 Wires, Shielded XS108B3PAM8 - main
Shop TELEMECANIQUE SENSORS

Cylindrical, Inductive Proximity Sensor, 13 mm Dia., Stainless Steel, M8, 3 Wires, Shielded

  • Mfr # XS108B3PAM8

  • Zoro # G0563757

product price:  $87.89
/ea
Free Shipping & Returns

Key Features

Measurement Range
0 to 2 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 24V DC
Length
42 mm
Proximity Sensor Electrical Connection
Male Connector M8, 3 Pins
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
XS108B3PAM8
Zoro #
G0563757
UPC #
785901683957
Country of Origin
Indonesia

Dimensions

Length
42 mm
Overall Diameter
13 mm
Overall Height
42 mm

Details

Item
Proximity Sensor
Measurement Range
0 to 2 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 24V DC
Proximity Sensor Electrical Connection
Male Connector M8, 3 Pins
Proximity Sensor Operating Frequency
Less than Or Equal to 2500 Hz
Electrical Connection
M8
Description/Special Features
Frontal Detection Face; Output State 1 LED Yellow
Standards
CE, CSA, UL Listed
Max. Current Load
10 mA
Operating Temp. Range
-25 to 70 Degrees C
IP Rating
IP65, IP67
Switching Capacity
<= 200 mA overload and short-circuit protection
Series
XS1
Maximum Voltage Drop
<2 V closed)
Maximum Delay Response
0.2 ms
Maximum Delay First Up
10 ms
Differential Travel
1...15% of Sr
Application
general purpose
Maximum Delay Recovery
0.2 ms
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Supply Voltage Limits
10-36 V DC
Storage Temp. Range
-40-85 °C
Body Type
fixed
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Features
Overload Protection, Reverse Polarity Protection, Short Circuit Protection
Style
Cylindrical, Inductive
Number of Pins
3
Output Circuit Contact Form
NO
Operating Temperature - Maximum
158 Degrees F
Sensing Face Shielding
Shielded
Operating Temperature - Minimum
-13 Degrees F
Includes Indicator Lights
Indicator Lights Included
Electrical Installation Type
Direct Connector
Output Circuit Number of Wires
3
Sensing Distance - Maximum
3 mm
DC Voltage Rating
12-24V DC
Switching Frequency
2,500 Hz
Output Circuit Type
PNP
Body Material
Stainless Steel
AC Voltage Rating
Not Rated
Body Stainless Steel Grade
303

Description

Inductive Cylindrical Proximity Sensor, IP Rating IP65, IP67, Standards CE, CSA, UL Listed
