  11. Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, M12, 3 Wires, Shielded
Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, M12, 3 Wires, Shielded XS630B1PAM12 - main

Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, M12, 3 Wires, Shielded

  • Mfr # XS630B1PAM12

  • Zoro # G6922912

product price: $110.99
/ea
Free Shipping & Returns

Key Features

Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Length
74 mm
Proximity Sensor Electrical Connection
4 Pin M12 Connector
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS630B1PAM12
Zoro #
G6922912
UPC #
785901505266
Country of Origin
Multiple

Dimensions

Length
74 mm
Overall Height
74 mm
Overall Diameter
30 mm

Details

Item
Inductive Cylindrical Proximity Sensor
Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Proximity Sensor Electrical Connection
4 Pin M12 Connector
Proximity Sensor Operating Frequency
500 Hz
IP Rating
IP67, IP69K
Max. Current Load
200mA
Operating Temp. Range
-13 Degrees to 158 Degrees F
Description/Special Features
Limit Switch Style Inductive Proximity Sensor
Standards
CE, CSA, E2, RoHS, UL Listed
Electrical Connection
M12
Differential Travel
1...15% of Sr
Supply Voltage Limits
10-58 V DC
Maximum Delay Recovery
1.4 ms
Maximum Delay First Up
10 ms
Body Type
fixed
Storage Temp. Range
-40-85 °C
Maximum Voltage Drop
<2 V closed)
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Switching Capacity
<= 200 mA DC overload and short-circuit protection
Series
XS6
Maximum Delay Response
0.6 ms
Application
mobile equipment; general purpose
Electrical Installation Type
Direct Connector
Sensing Distance - Maximum
15 mm
Output Circuit Number of Wires
3
Output Circuit Contact Form
NO
Body Finish
Nickel Plated
Body Material
Brass
Sensing Distance - Minimum
8 mm
Number of Pins
4
AC Voltage Rating
Not Rated
Operating Temperature - Minimum
-13 Degrees F
Sensing Face Shielding
Shielded
Style
Cylindrical
Load Current - Maximum
200 mA
Output Circuit Type
PNP
Includes Indicator Lights
Indicator Lights Included
Operating Temperature - Maximum
158 Degrees F
DC Voltage Rating
12-48V DC
Switching Frequency
500 Hz

Description

Inductive Cylindrical Proximity Sensor, Inductive, 30 mm, Proximity Sensor Power Requirement 12 to 48V DC, Shielded, Proximity Sensor Operating Frequency 500 Hz, Proximity Sensor Output Circuit Type 3 Wire PNP, Max. Detecting Distance 15 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NO, IP Rating IP67, IP69K, Case Material Nickel Plated Brass, Length 74 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
