  11. Cylindrical, Inductive Proximity Sensor, 36 mm Dia., Brass, 5 m, Bare Wire, 2 Wires, Shielded
Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 36 mm Dia., Brass, 5 m, Bare Wire, 2 Wires, Shielded XS630B1MAL5 - main

Cylindrical, Inductive Proximity Sensor, 36 mm Dia., Brass, 5 m, Bare Wire, 2 Wires, Shielded

  • Mfr # XS630B1MAL5

  • Zoro # G0478110

product price: $116.99
/ea
Free Shipping & Returns

Key Features

Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Length
62 mm
Proximity Sensor Electrical Connection
Cable Connection
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS630B1MAL5
Zoro #
G0478110
UPC #
785901446347
Country of Origin
Multiple

Dimensions

Length
62 mm
Cable Length
5 m
Overall Diameter
36 mm
Overall Height
62 mm

Details

Item
Proximity Sensor
Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Proximity Sensor Electrical Connection
Cable Connection
Proximity Sensor Operating Frequency
Less than Or Equal to 25 Hz AC; Less than Or Equal to 500 Hz DC
Standards
CE, CSA, UL Listed
Operating Temp. Range
-25 to 70 Degrees C
IP Rating
IP68, IP69K
Electrical Connection
Bare Wire
Description/Special Features
Frontal Detection Face; Output State 1 LED Yellow
Switching Capacity
5...200 mA DC || 5...300 mA AC
Maximum Delay First Up
25 ms
Maximum Voltage Drop
<5.5 V closed)
Application
general purpose
Series
XS6
Differential Travel
1...15% of Sr
Storage Temp. Range
-40-85 °C
Maximum Delay Recovery
2 ms
Supply Voltage Limits
20-264 V AC/DC
Maximum Delay Response
0.5 ms
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Body Type
fixed
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Features
Flush Mountable
AC Voltage Rating
24-240V AC
Sensing Distance - Minimum
8 mm
Body Finish
Nickel Plated
Operating Temperature - Minimum
-13 Degrees F
Electrical Installation Type
Prewired Cable
DC Voltage Rating
24-240V DC
Operating Temperature - Maximum
158 Degrees F
Output Circuit Number of Wires
2
Switching Frequency
25 Hz (AC), 500 Hz (DC)
Style
Cylindrical, Inductive
Sensing Face Shielding
Shielded
Sensing Distance - Maximum
15 mm
Body Material
Brass
Includes Indicator Lights
Indicator Lights Included
Output Circuit Contact Form
NO
Output Circuit Type
AC/DC-Type

Description

Inductive Cylindrical Proximity Sensor, IP Rating IP68, IP69K, Standards CE, CSA, UL Listed
