Shop TELEMECANIQUE SENSORS

Inductive, Rectangular Proximity Sensor, PBT, Bare Wire, 2 Wires, Shielded

  • Mfr # XS8C4A1MPG13

  • Zoro # G6423873

product price:
$
202.99
/ea
Free Shipping & Returns

Key Features

Style
Inductive, Rectangular
Measurement Range
0 to 16 mm
Proximity Sensing Method
Inductive
Body Material
PBT
Proximity Sensor Power Requirement
24 to 240V AC/DC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
XS8C4A1MPG13
Zoro #
G6423873
UPC #
-
Country of Origin
Indonesia
Item
Proximity Sensor
Style
Inductive, Rectangular
Measurement Range
0 to 16 mm
Proximity Sensing Method
Inductive
Body Material
PBT
Proximity Sensor Power Requirement
24 to 240V AC/DC
Electrical Connection
Bare Wire
Output Circuit Type
Programmable
Output Circuit Number of Wires
2
Sensing Face Shielding
Shielded
Sensing Distance - Maximum
20 mm
AC Voltage Rating
24-240V AC
DC Voltage Rating
24-240V DC
Output Circuit Contact Form
NO/NC
Standards
CCC, CE, CSA, RoHS, UL Listed
Proximity Sensor Electrical Connection
PG13, Screw Terminal
Proximity Sensor Operating Frequency
300 Hz
Max. Current Load
200 mA, 300 mA
Description/Special Features
Limit Switch Style Inductive Proximity Sensor
Operating Temp. Range
-13 Degrees to 158 Degrees F
IP Rating
IP65, IP67, IP69K
Body Type
fixed
Switching Capacity
5...200 mA DC || 5...300 mA AC
Application
general purpose
Maximum Voltage Drop
<5.5 V closed)
Series
XS8
Storage Temp. Range
-40-85 °C
Maximum Delay Response
1.2 ms
Differential Travel
3...15% of Sr
Shock Resistance
50 gn 11 msEN 60068-2-27
Maximum Delay Recovery
1.8 ms
Supply Voltage Limits
20-264 V AC/DC
Maximum Delay First Up
7.5 ms
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Load Current - Maximum
300 mA
Electrical Installation Type
Screw Clamp Terminal
Includes Indicator Lights
Indicator Lights Included
Sensing Method
Inductive
Operating Temperature - Minimum
-13 Degrees F
Operating Temperature - Maximum
158 Degrees F
Switching Frequency
25 Hz (AC), 50 Hz (DC)

Description

Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 24 to 240V AC/DC, Shielded, Proximity Sensor Operating Frequency 300 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 20 mm, Proximity Sensor Electrical Connection PG13, Screw Terminal, Output Mode NO/NC, IP Rating IP65, IP67, IP69K, Case Material PBT, Length 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200 mA, 300 mA
