  11. Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Unshielded
Telemecanique Sensors Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Unshielded XS8C2A4PCM12 - main

Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Unshielded

  • Mfr # XS8C2A4PCM12

  • Zoro # G4575417

product price: $93.39
/ea
Free Shipping & Returns

Key Features

Proximity Sensor Style
Rectangular Proximity Sensor
Measurement Range
0 to 32 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Length
40 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS8C2A4PCM12
Zoro #
G4575417
UPC #
785901931737
Country of Origin
Indonesia

Dimensions

Length
40 mm
Width
40 mm
Depth
70 mm
Overall Depth
40 mm
Overall Height
70 mm
Overall Width
40 mm

Details

Item
Proximity Sensor
Proximity Sensor Style
Rectangular Proximity Sensor
Measurement Range
0 to 32 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Proximity Sensor Electrical Connection
4 Pin M12 Male Connector
Proximity Sensor Operating Frequency
500 Hz
Standards
CCC, CE, CSA, E2, RoHS, UL Listed
Description/Special Features
1 Green LED for Supply On, Overload and Short-Circuit Protection, Reverse Polarity Protection
IP Rating
IP65, IP67, IP69K
Max. Current Load
200mA
Operating Temp. Range
-13 Degrees to 158 Degrees F
Electrical Connection
M12
Switching Capacity
<= 200 mA overload and short-circuit protection
Series
XS8
Maximum Voltage Drop
<2 V closed)
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Maximum Delay First Up
7.5 ms
Shock Resistance
50 gn 11 msEN 60068-2-27
Supply Voltage Limits
10-58 V DC
Application
mobile equipment; general purpose
Body Type
fixed
Storage Temp. Range
-40-85 °C
Maximum Delay Recovery
2.5 ms
Maximum Delay Response
1.4 ms
Differential Travel
3...15% of Sr
Sensing Distance - Maximum
40 mm
Electrical Installation Type
Direct Connector
AC Voltage Rating
Not Rated
Operating Temperature - Minimum
-13 Degrees F
Output Circuit Number of Wires
3
Sensing Face Shielding
Unshielded
Output Circuit Type
PNP
Style
Inductive, Rectangular
DC Voltage Rating
12-48V DC
Operating Temperature - Maximum
158 Degrees F
Features
Overload Protection, Reverse Polarity Protection, Short Circuit Protection
Load Current - Maximum
200 mA
Number of Pins
4
Body Material
PBT
Switching Frequency
500 Hz
Includes Indicator Lights
Indicator Lights Included
Output Circuit Contact Form
NO/NC

Description

Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 12 to 48V DC, Unshielded, Proximity Sensor Operating Frequency 500 Hz, Proximity Sensor Output Circuit Type 3 Wire PNP, Max. Detecting Distance 40 mm, Proximity Sensor Electrical Connection 4 Pin M12 Male Connector, Output Mode NO/NC, IP Rating IP65, IP67, IP69K, Case Material Plastic, Length 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
