This item is Discontinued.

Telemecanique Sensors Photoelectric Sensor 18Mm Pnp Xub XUB9BPANM12

Photoelectric Sensor 18Mm Pnp Xub (Discontinued)

  • Mfr # XUB9BPANM12
  • Zoro # G0839365
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XUB9BPANM12
Zoro #
G0839365
UPC #
785901821595
Country of Origin
Multiple

Dimensions

Diameter
18 mm
Overall Height
18 mm
Length
62 mm
Overall Width
62 mm

Details

Item
Photoelectric Sensor
Material
metal
Body Material
Brass
Response Time
1 msec
Features
Overload Protection, Short Circuit Protection
IP Rating
IP65, IP67, IP69K
Electrical Connection
M12
Sensing Method
Polarized Retroreflective
Current Consumption
35 mA no-load
Standards
CE, CSA, EU RoHS, UL Listed
Sensor Name
XUB
[Us] Rated Supply Voltage
12...24 V DC reverse polarity protection
Maximum Delay Recovery
1 ms
Maximum Delay Response
1 ms
Switching Frequency
<= 500 Hz
Maximum Voltage Drop
<1.5 V closed state)
Ambient Air Temperature For Operation
-25-55°C
Setting-Up
without sensitivity adjustment
Enclosure Material
Nickel Plated Brass
Wiring Technique
3-wire
Maximum Sensing Distance
3 m polarised reflex
Type Of Output Signal
discrete
Switching Capacity In Ma
<= 100 mA overload and short-circuit protection)
Discrete Output Function
1 NO
Maximum Delay First Up
15 ms
Sensor Design
cylindrical M18
Electronic Sensor Type
photo-electric sensor
Emission
red polarised reflex
Line Of Sight Type
axial
Discrete Output Type
PNP
Supply Circuit Type
DC
Wire Insulation Material
PvR
[Sn] Nominal Sensing Distance
2-2 m polarised reflex need reflector XUZC50
Detection System
polarised reflex
Add On Output
without
Product Certifications
CE || UL || CSA
Ip Degree Of Protection
IP67 double insulation IEC 60529 || IP65 double insulation IEC 60529 || IP69K double insulation DIN 40050
Supply Voltage Limits
10-36 V DC
Shock Resistance
30 gn 11 ms) IEC 60068-2-27
Ambient Air Temperature For Storage
-40-70°C
Lens Material
PMMA
Output Type
solid state
Status Led
1 LED yellow)output state
Vibration Resistance
7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
Series Name
general purpose single mode
Operating Temperature - Minimum
-13 Degrees F
Sensing Distance - Maximum
3 m
Operating Temperature - Maximum
131 Degrees F
Style
Rectangular
Product Type
Photoelectric Sensor
Number of Pins
4

Description

Photoelectric Sensor
