Specifications
Product Information
MFR #
XSAV11801L10
Zoro #
G500899231
UPC #
-
Country of Origin
France
Dimensions
Length
81 mm
Details
Item
Rot. monitoring - M30 - Sn10mm - 6..150c
Proximity Sensor Style
Cylindrical M30
Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 210V DC; 24 to 240V AC
Proximity Sensor Output Circuit Type
2-Wire AC/DC
Output Mode
1 NC
Max. Detecting Distance
10 mm
Standards
CSA; UL; CCC; CE Marked
Proximity Sensor Electrical Connection
Cable Connection
Basic Proximity Sensor Case Material
Nickel Plated Brass; PPS
Proximity Sensor Operating Frequency
Less than Or Equal to 100 Hz
Description/Special Features
Frontal Detection Face; Output State 1 LED Red
IP Rating
IP67
Operating Temp. Range
-25 to 70 Degrees C
Application
rotation monitoring
Differential Travel
3...15% of Fr
Switching Capacity
5...200 mA DC || 5...350 mA AC
Supply Voltage Limits
20-264 V AC/DC
Storage Temp. Range
-40-85 °C
Maximum Voltage Drop
<5.7 V closed)
Series
XSA
Body Type
fixed
Description
Rot. monitoring - M30 - Sn10mm - 6..150c
