This item is Discontinued.
Telemecanique Sensors Sensor Inductive XS108B3PAM12

Sensor Inductive (Discontinued)

  • Mfr # XS108B3PAM12
  • Zoro # G0839557
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS108B3PAM12
Zoro #
G0839557
UPC #
785901628286
Country of Origin
Multiple

Dimensions

Length
45 mm
Overall Height
45 mm

Details

Item
Inductive Proximity Sensor
Proximity Sensor Style
Cylindrical M8
Measurement Range
0 to 2 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 24V DC
Proximity Sensor Output Circuit Type
3-Wire DC PNP
Output Mode
1 NO
Max. Detecting Distance
2.5 mm
Proximity Sensor Electrical Connection
Male Connector M12, 4 Pins
Basic Proximity Sensor Case Material
Stainless Steel 303; PPS
Proximity Sensor Operating Frequency
Less than Or Equal to 2500 Hz
IP Rating
IP65, IP67
Max. Current Load
10 mA
Electrical Connection
M12
Standards
CE, CSA, REACH, RoHS, UL Listed
Description/Special Features
Frontal Detection Face; Output State 1 LED Yellow
Operating Temp. Range
-25 to 70 Degrees C
Features
18 months Warranty, Yellow LED Output Indication
Application
general purpose
Maximum Delay Recovery
0.2 ms
Differential Travel
1...15% of Sr
Maximum Voltage Drop
<2 V closed)
Maximum Delay First Up
10 ms
Supply Voltage Limits
10-36 V DC
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Body Type
fixed
Switching Capacity
<= 200 mA overload and short-circuit protection
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Storage Temp. Range
-40-85 °C
Series
XS1
Maximum Delay Response
0.2 ms
Output Circuit Type
PNP
Operating Temperature - Maximum
158 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Load Current - Maximum
10 mA
Switching Frequency
2,500 Hz
Output Circuit Contact Form
NO
Sensing Distance - Maximum
3 mm
Sensing Method
Inductive
Body Material
Stainless Steel

Description

Inductive Proximity Sensor, IP Rating IP65, IP67, Standards CE, CSA, REACH, RoHS, UL Listed
