  9. Panel-Mount Compound Gauge, 30 to 0 to 400 psi, 4 in Dial, 1/4 in NPT, Lower Back Location
Thuemling Panel-Mount Compound Gauge, 30 to 0 to 400 psi, 4 in Dial, 1/4 in NPT, Lower Back Location BC-LFP-100-E - main

Panel-Mount Compound Gauge, 30 to 0 to 400 psi, 4 in Dial, 1/4 in NPT, Lower Back Location

  • Mfr # BC-LFP-100-E

  • Zoro # G6300290

product price: $158.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.0%
Process Connection Location
Lower Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BC-LFP-100-E
Zoro #
G6300290
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
4 in
Nominal Dial Size
4 in
Manufacturer Warranty Length
1 yr
Case Diameter
4.21 in
Case Depth
1.85 in
Nominal Dial Diameter
4 in

Details

Item
Panel-Mount Compound Gauge
Accuracy
+/-1.0%
Process Connection Location
Lower Back
Process Connection Type
NPT
Application
Fire Monitoring
Gauge Case Material
Cast Brass
Series
BC
Lens Material
Acrylic
Primary Pressure Range
30 to 0 to 400
Primary Scale Units
in Hg/psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
Yes
Hazardous Location Rating
Not Rated
Panel-Mountable
Yes
Blowout Safety Back
No
Gauge Filled With
Glycerin
Gauge Secondary Range Values
0 to 30
Case Color
Black
For Use With
Media Compatible with Bronze
Gauge Application
Fire Apparatus Panels
Gauge Primary Range Smallest Graduation
5
Calibration Certificate Included
No
Gauge Mounting Method
U Clamp
Smallest Graduation
5 psi
Socket Material
Brass
Case Material
Cast Brass
Standards
ASME
Connection Type
MNPT
Wetted Materials
Brass / Bronze
Includes Vent Plug
No
Sensor Type
Bourdon Tube
Accuracy Scale
Full Scale
Dry Dampening Feature
None
Removable Bezel
No
Pressure Gauge Type
Industrial Pressure Gauge
Gauge Case Liquid
Glycerin
Pressure Range Type
Compound
Field Fillable
No
Cleaned for Oxygen Service
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Dial Face Material
Aluminum
Primary Scale Minor Graduations
10
Non-Sparking
No
Vibration Resistance
Liquid-Filled
Primary Pressure Scale Color
Black
Accuracy Grade
ASME B40.100 Grade 1A
Case Construction
Corrosion Resistant
Dial Color
White
Includes Calibration Certificate
No
Process Connection Gender
Male
Pointer Material
Aluminum
Compatible Process Media
Liquid
Includes Mounting Hardware
No
Bezel Material
Chrome
Panel Mount Characteristics
Mounting Studs
Scale Type
Single
Sensor Material
Bronze
Freeze Resistant Movement
No
Pointer Color
Black
Maximum Pressure
400
Operating Temperature Range
-40 Degrees to 150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
150 Degrees F
Compatible with Series
Universal
Primary Scale Color
Black
IP Rating
IP65
Primary Scale Pressure Measurement - Maximum
400 psi
Process Media Temperature - Maximum
140 Degrees F
Compatible with Brand
SPAN
Primary Scale Pressure Measurement - Minimum
0 psi
Operating Temperature - Minimum
-40 Degrees F
Case Liquid
Glycerin
Primary Scale Vacuum Measurement - Minimum
0 in Hg
Primary Scale Vacuum Measurement - Maximum
30 in Hg
NEMA Enclosure Rating
4

Description

Panel-Mount Compound Gauge, Nominal Dial Size 4 in, Accuracy +/-1.0 Percent, Gauge Case Material Cast Brass, Process Connection Type NPT, Process Connection Gender Male, Lens Material Acrylic, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Lower Back, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 30 to 0 to 400, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color White, Pressure Gauge Type Industrial Pressure Gauge
