Radial Bearing, Double Shield, 45mm Bore
Mfr # 309WDD
Zoro # G8111521
product price: $192.99
/ea
Free Shipping & Returns
Key Features
Bearing Type
Double Shield
Single Row/Double Row
Single Row
Cage Material
Steel
Seal/Shield Type
Double Shielded
Bore Dia.
45 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
309WDD
Zoro #
G8111521
UPC #
087796042957
Country of Origin
Multiple
Dimensions
Bore Dia.
45 mm
Outside Dia.
100 mm
Width
25 mm
Outside Dia. Tolerance
+0/-.015mm
Outside Diameter
100 mm
Bore Diameter
45 mm
Fillet Radius
1.5 mm
Bore Diameter Tolerance
+0/-0.012 mm
Outer Ring Width
25 mm
Outside Diameter Tolerance
+0/-0.015 mm
Description
Radial Ball Bearing, Bearing Industry Number 6309, Bore Diameter 45 mm, Closure Double Shielded, Outer Ring Width 25 mm, Outside Diameter 100 mm, Ring Material Alloy Steel, System of Measurement Metric, Cage Material Steel, ABEC Rating 1, Ball Material Alloy Steel, Bore Diameter Tolerance +0/-0.012 mm, Dynamic Radial Load Capacity 76,700 N, Fillet Radius 1.5 mm, Includes Retaining Ring No, Lubricant Material SRI 2
