Shop TRANSAIR

Tubing Fitting, For Tubing O.D.1 40.00mm

  • Mfr # 4092 40 00

  • Zoro # G2148214

product price:  $234.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
1/2"
Body Material
Plated Brass
Standards
ASME B31.1, ASME B31.3, ATEX Directive 2014/34/EU, CE Directive 2014/68/EU, EN 13501-1, EN 13501-2, IATF 16949 Version 2016 Certified, ISO 14001, ISO 8573, ISO 9001 Version 2015, Labs Free Compliance, Oil Free Certificate, Qualicoat Certification, REACH
Type
Ball Valve
For Tubing O.D. 2
40 mm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
4092 40 00
Zoro #
G2148214
UPC #
-
Country of Origin
France

Dimensions

Pipe Size
1/2"
Fitting Size (NPT)
1 in
Overall Length
8.07 in
Fitting Side B Tube Outer Diameter
1 1/2 in
Fitting Side A Tube Outer Diameter
1 1/2 in
Connection Size - Side 1
1 1/2 in
Connection Size - Side 2
1 1/2 in
Wire Rope Length
8.07 in

Details

Body Material
Plated Brass
Standards
ASME B31.1, ASME B31.3, ATEX Directive 2014/34/EU, CE Directive 2014/68/EU, EN 13501-1, EN 13501-2, IATF 16949 Version 2016 Certified, ISO 14001, ISO 8573, ISO 9001 Version 2015, Labs Free Compliance, Oil Free Certificate, Qualicoat Certification, REACH
Type
Ball Valve
For Tubing O.D. 2
40 mm
Item
Lockable Ball Valve
Color
Black
Material
Plated Brass
For Tubing O.D. 1
40 mm
Application
Air, Inert Gases, Vacuum
Specific Fitting Shape
Ball Valve
Fitting Material
Brass
Maximum Operating Pressure
232 psi
Maximum Operating Temperature
140 Degrees F
Fitting Side B Connection Type
Push-to-Connect
Resistance Properties
Chemical-Resistant, Corrosion-Resistant
Fitting Side A Connection Type
Push-to-Connect
Minimum Operating Temperature
4 Degrees F
System of Measurement
Imperial
Compatible Tube Material
Aluminum
Vacuum Rating
29.6 inHg
Vacuum Service Rating
29.6 in Hg
Color - Valve Body
Black
Operating Temperature - Minimum
4 Degrees F
Maximum Pressure - Operating
232 psi
Valve Series
Transair
Operating Temperature - Maximum
140 Degrees F
For Media
Air, Gases
Connection Type - Side 1
Push
Connection Type - Side 2
Push

Description

Lockable Ball Valve, Body Material Brass, For Media Air, Gases, Maximum Pressure - Operating 232 psi, Vacuum Service Rating 29.6 in Hg, Connection Size - Side 1 1 1/2 in, Connection Size - Side 2 1 1/2 in, Connection Type - Side 1 Push, Connection Type - Side 2 Push, Operating Temperature - Minimum 4 Degrees F

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
