  9. Analog Multimeter, 600 V, 30 A, 100 ohm
Triplett Analog Multimeter, 600 V, 30 A, 100 ohm 2011 - main

Analog Multimeter, 600 V, 30 A, 100 ohm

  • Mfr # 2011

  • Zoro # G8107057

product price: $2,054.99
/ea
Free Shipping & Returns

Key Features

Max. AC Volts
600 V
Includes
Padded Water Repellent Carrying Case, Shoulder Strap, Test Leads
Battery Type
9V, D
Max. DC Volts
300 V
Accuracy
+/-3% Scale Length
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2011
Zoro #
G8107057
UPC #
614395001148
Country of Origin
Taiwan, Province of China

Dimensions

Overall Width
3.2 in
Overall Height
6.5 in
Battery Size
9V; D
Manufacturers Warranty Length
1 yr

Details

Item
Analog Railroad Tester
Max. AC Volts
600 V
Includes
Padded Water Repellent Carrying Case, Shoulder Strap, Test Leads
Battery Type
9V, D
Max. DC Volts
300 V
Accuracy
+/-3% Scale Length
Mirrored Scale
Yes
Sensitivity
1,000 ohm/V
Overload Protector
Yes
Max. Ohms
1000 ohm
AC Frequency Response
25 to 400 Hz
Max. DC Amps
30 A
Movement
100 Degree Deflection, Critically Damped, High Strength Magnet, Mirrored, Shock Mounted, Taut Band
Max. AC Amps
30 A
Special Features
Auto Polarity in DC Functions, Base Unit with No Cab Filters, Auto and Selectable DC Amps Polarity, Direct Measurement of Code Parameters, Ohmmeter Voltage Mode Detects Foreign AC or DC Voltages, Peak Measurements Require No Adjustment, Relay Contact on Time (Dry Contact) Requires No Adjustment
Audible Continuity
No
Calibration Certificate Included
No
Minimum Operating Temperature
-40 Degrees F
Basic AC Current Accuracy
+/-1.50%
Parameters Measured
AC Current, AC Voltage, DC Current, DC Voltage, Resistance
Batteries Included
Yes
Basic AC Voltage Accuracy
+/-3.00%
Maximum AC Current Measurement
30 A
Minimum AC Voltage Measurement
1.5 V
Minimum DC Voltage Measurement
0.6 V
Resistance Measurement Accuracy
+/-2.00%
Maximum Resistance Measurement
100 ohm
Minimum DC Current Measurement
1.5 A
Minimum Storage Temperature
-40 Degrees F
Maximum Operating Temperature
185 Degrees F
Battery Voltage
1.5V DC; 9V DC
Basic DC Voltage Accuracy
+/-1.50%
Maximum DC Current Measurement
30 A
Basic DC Current Accuracy
+/-1.50%
Maximum AC Voltage Measurement
600 V
Maximum Storage Temperature
185 Degrees F
Maximum DC Voltage Measurement
300 V
Minimum AC Current Measurement
0 A
Minimum Resistance Measurement
0 ohm

Description

Analog Multimeter, Basic AC Current Accuracy +/-1.50 Percent, Resistance Measurement Accuracy +/-2.00 Percent, Basic DC Current Accuracy +/-1.50 Percent, AC Frequency Response 25 to 400 Hz, Parameters Measured AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Basic AC Voltage Accuracy +/-3.00 Percent, Basic DC Voltage Accuracy +/-1.50 Percent, Minimum AC Voltage Measurement 1.5 V, Maximum AC Voltage Measurement 600 V, Minimum DC Voltage Measurement 0.6 V
