Cat5e Cable, Snagless, Molded, Blue, 10ft

Cat5e Cable, Snagless, Molded, Blue, 10ft

Mfr # N001-010-BL
Zoro # G5186907

$4.19

Sold in multiples of 2 for $8.38

Key Features

Connector Type - Patch Cord

RJ45 (Male); RJ45 (Male)

Boot Type - Data cable

Snagless

Length - Patch Cord

10 ft

Transmission Speed

1 Gbps

Cable Jacket Color

Blue

See all product information

Get a 10% off coupon

Free 30-day returns

Return Policy

Get 30 days to pay with Net 30

Apply Now

Real support from real people

Contact our U.S. based team

Specifications

Product Information

MFR #

N001-010-BL

Zoro #

G5186907

UPC #

037332042545

Country of Origin

China

Dimensions

Length - Patch Cord

10 ft

Cable Length

10 ft

Bandwidth per TIA Standard

100 MHz

Cable Length (ft.)

Maximum Bandwidth as Tested

350 MHz

Cable Outer Diameter (OD)

5.0 mm

Details

Item

Cat5e Cable,Snagless,Molded,Blue,10ft

Connector Type - Patch Cord

RJ45 (Male); RJ45 (Male)

Boot Type - Data cable

Snagless

Transmission Speed

1 Gbps

Cable Jacket Color

Blue

Cable Jacket Material

PVC

Cable Type

Category 5e

Jacket Color

Blue

Connector Type

Molded; Snagless

Shielded

Jacket Material

Polyvinyl Chloride (PVC)

Category - Data Cable

5/5e

Solid / Stranded

Stranded

Conductor Material

Stranded Copper

Shielding Type

UTP

Product Color

Blue

Connector on Second End Details

1 x RJ-45 - Male

Conductor

Copper

Additional Information

Cabling for category 5 (Cat5) and 5e (Cat5e) applications, Molded connectors with integral strain relief, Snagless design protects the locking tabs on the RJ45 connectors from being damaged or snapped off during installation Applications: 1000Base-T (1Gbps Ethernet), 10/100Base-T (Ethernet), 100 Mbps TPDDI, 155 Mbps ATM, ISDN, Voice, Token Ring Type3 applications

Certifications & Standards

Meets most current industry standards including: IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801, ETL (category 5e draft 11)

Package Contents

Cat5e Patch Cable, 10-ft. Blue Snagless Cat5e Patch Cable

Product Name

Cat5e Patch Cable

Connector on First End Details

1 x RJ-45 - Male

Cable Characteristic

Patch Cable

Product Type

Network Cable

Product Compliance

CE (Europe); IEEE 802.3ab 1000Base-T; IEEE 802.3at PoE+; UKCA

Wiring Configuration

EIA/TIA 568B

Operating Humidity Range

0% to 90% RH, Non-Condensing

Number of Conductors

4 Pair

Contact Plating

Gold

Technology

Cat5/5e

Side B - Connector 1

RJ45 (MALE)

Network Compatibility

1 Gbps (Gigabit)

Operating Temperature Range

14Â° to 104Â°F (-10Â° to 40Â°C)

Cable Jacket Rating

Package Includes

10-ft. (3.05 m) Blue Snagless Cat5e Patch Cable

IEEE Standards Supported

802.3ab; 802.3at

Power Over Cable (PoC) Support

Conductor Gauge

26 AWG

Storage Humidity Range

0% to 90% RH, Non-Condensing

Storage Temperature Range

5Â° to 122Â°F (-15Â° to 50Â°C)

Cable Shielding

UTP

Product Certifications

UL Listed; cUL Listed

PoE Type

Type 2 PoE+ (30W, IEEE 802.3at)

Side A - Connector 1

RJ45 (MALE)

Description

Cat5e Cable,Snagless,Molded,Blue,10ft
