- Item
- Outlet Strip
- Type
- Surge
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); cUL Listed; NOM (Mexico); UL 1449; UL 1363; UL Listed; RoHS
- Housing Material
- Plastic
- Voltage
- 120VAC
- Coax Surge Protection
- No
- Mounting Style
- Keyhole
- Circuit Breaker
- Yes
- Outlet Surge Protection
- Yes
- NEC Cord Designation
- 14 ga., SJT
- Power Indicator
- Yes
- Number of Transformer Outlets
- 4
- NEMA Plug Configuration
- NEMA 5-15P
- NEMA Receptacle Configuration
- NEMA 5-15R
- Number of Outlets
- 7
- Number of Outlet Rows
- 1
- Rated Joules
- 2160 J
- Hz
- 50/60 Hz
- Noise Attenuation
- Up to 20 dB
- Outlet Center Distance
- 29 mm Standard; 48 mm Transformer
- Max. Amps
- 15A
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Input Voltage
- 120 V AC
- Package Contents
- Protect It! 7-Outlet Surge Protector, 25 ft. Cord, 2160 Joules, Black Housing, Owner's Manual
- Power Handling
- 1800 VA
- Surge Energy Rating
- 2160 J
- Outlets Measurement (Center to Center)
- Between Standard Outlets = 29mm; Between Transformer Outlets = 48mm
- Diagnostic LED(s)
- Yes
- Outlet Orientation
- Single row of 5, plus 2 side mounted outlets
- Input Plug Features
- Right Angle (36D)
- AC Suppression Response Time
- < 1 ns
- Input Cord Details
- SJT
- Nominal Input Voltage(s) Supported
- 120V AC
- AC Suppression Joule Rating
- 2160
- Network (Ethernet) Protection
- No
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Frequency Compatibility
- 50 / 60 Hz
- Maximum Surge Amps
- 144000
- Package Includes
- SUPER725B Protect It! 7-Outlet Surge Protector, 25-ft. (7.62 m) Cord, Black Housing;Owner's manual
- Circuit Breaker (amps)
- 15
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Output Receptacles
- (7) 5-15R
- Mounting Holes or Slots
- Yes
- Material of Construction
- Plastic
- EMI / RFI Filtering
- Up to 20 dB
- Product Type
- Surge Protector Outlet Strip
