- MFR #
- TLP76MSG
- Zoro #
- G4261056
- UPC #
- 037332166074
- Country of Origin
- China
- Item
- Outlet Strip
- Type
- Surge
- Total Number of Outlets
- 7
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Gray
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); cUL Listed; NOM (Mexico); UL 1449; UL 1363; UL Listed; RoHS
- Footnotes
- 19
- Hz
- 60 Hz
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- Voltage
- 120VAC
- Max. Amps
- 15A
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- Includes
- Individual Outlet Control, Instruction Manual and Warranty Information
- Power Indicator
- Yes
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 7
- Color - Ext. Cords and Outlet Strips
- Gray
- Housing Material
- Plastic
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Noise Attenuation
- Up to 40dB
- NEMA Receptacle Configuration
- NEMA 5-15R
- NEC Cord Designation
- SJT
- Rated Joules
- 1,080
- NEMA Plug Configuration
- NEMA 5-15P
- Number of Outlets
- 7
- Max. Surge Current
- 72 kA
- Green Environmental Attribute
- RoHS 2011/65/EU Compliant
- Medical Grade
- No
- For Use With
- Desktop, Network Or Home Computing Application Requiring AC Protection
- Mounting Style
- Keyhole
- Number of Transformer Outlets
- 1
- Outlet Surge Protection
- Yes
- Coax Surge Protection
- No
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Special Features
- Individual Outlet Control
- Communication Port
- None
- Application
- Home; Office
- USB Charging Port
- 0
- Trade Designation
- SJT
- Number of Conductors
- 3
- Frequency
- 60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Compatibility
- Computers/Peripherals
- Surge Energy Rating
- 1080 J
- Output Voltage
- 125 V AC
- Input Voltage
- 125 V AC
- Package Contents
- ECO-SURGE TLP76MSG 7-Outlets Surge Suppressor, Instruction Manual with Warranty Information
- Power Handling
- 1800 VA
- Output Capacity (Watts)
- 1800
- Individually Controllable Load Banks
- Yes
- EMI / RFI Filtering
- Up to 40 dB
- AC Suppression Joule Rating
- 1080
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Frequency Compatibility
- 60 Hz
- AC Suppression Response Time
- < 1 ns
- Maximum Surge Amps
- 72000
- Package Includes
- TLP76MSG ECO-SURGE Home/Business Theater Surge Suppressor;Instruction manual with warranty information
- Diagnostic LED(s)
- Yes
- Network (Ethernet) Protection
- No
- Material of Construction
- Plastic
- Nominal Input Voltage(s) Supported
- 120V AC
- Mounting Holes or Slots
- No
- Output Receptacles
- (7) 5-15R
- LED Indicators
- Protected (Green)" & Always On Receptacle (Red)
- Input Cord Details
- SJT
- Output Capacity (VA)
- 120
- Plug Style
- Straight
- Maximum Current
- 15 A
- Rated Energy Absorption
- 1,080 J
- Medical Facility Use UL Rating
- UL 1363
- Product Type
- Surge Protector Outlet Strip
- Maximum Surge Current
- 72 kA
