- Item
- Outlet Strip
- Type
- Surge, Tel/Modem/Coaxial Protection
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- IEEE 587; UL1363; UL1449; UL497A
- Circuit Breaker
- Yes
- Rated Joules
- 2880 J
- Hz
- 50/60 Hz
- Power Indicator
- Yes
- Coax Surge Protection
- Yes
- Communication Port
- FCC Part 68
- NEMA Receptacle Configuration
- NEMA 5-15R
- Voltage
- 120VAC
- Noise Attenuation
- Up to 40 dB
- Outlet Center Distance
- 25.4 mm Standard; 57 mm Transformer
- Mounting Style
- Keyhole
- Number of Transformer Outlets
- 8
- Outlet Surge Protection
- Yes
- Max. Amps
- 15A
- Number of Outlets
- 12
- Number of Outlet Rows
- 2
- NEMA Plug Configuration
- NEMA 5-15P
- NEC Cord Designation
- 14 ga., SJT
- Housing Material
- Plastic
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Circuit Breaker (amps)
- 15
- AC Suppression Response Time
- < 1 ns
- Outlet Orientation
- Two rows of outlets, including 4 widely spaced for transformers
- Package Includes
- TLP1208TELTV surge suppressor;6-ft. (1.83 m) RJ11 cable;1 set gold digital 2.2 GHz coax connectors;Instruction manual and warranty information
- Output Receptacles
- (12) 5-15R
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Material of Construction
- Plastic
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Input Cord Details
- SJT
- Overload Protection
- 15A resettable circuit breaker
- Nominal Input Voltage(s) Supported
- 120V AC
- Network (Ethernet) Protection
- No
- Frequency Compatibility
- 50 / 60 Hz
- Maximum Surge Amps
- 180000
- Mounting Holes or Slots
- Yes
- Cable (Coax) Protection
- Yes
- Diagnostic LED(s)
- Yes
- EMI / RFI Filtering
- Up to 40 dB
- AC Suppression Joule Rating
- 2880
- Input Plug Features
- Right Angle (36D)
- Outlets Measurement (Center to Center)
- Distance between standard outlets = 25.4mm; Distance between transformer outlets = 57mm
- Output Capacity (VA)
- 15
- Product Type
- Surge Protector Outlet Strip
