- Item
- PDU
- Type
- Monitored
- Receptacle Configuration
- (42) C13, (6) C19
- Plug Configuration
- IEC-60309 30A BLUE (3P+E)
- Standards
- RoHS Compliant; TAA Compliant
- Number of Outlets
- 48
- Max. Amps
- 24A
- NEMA Plug Configuration
- IEC-309 30A BLUE (3P+E)
- Mounting Style
- Vertical Rackmount/0U
- Voltage
- 208V
- Power Indicator
- Yes
- Housing Material
- Metal
- NEMA Receptacle Configuration
- (42) C13; (6) C19
- Frequency
- 50/60 Hz
- Mount Type
- Rack-mountable
- Receptacle Detail
- 30 x IEC 60320 C13, 6 x IEC 60320 C19
- PDU Type
- Monitored
- Output Voltage
- 208 V AC
- Package Contents
- Monitored PDU3VN10G30 36-Outlets 8.6kW PDU, Cord Retention Brackets, Rack Mounting Brackets, Owner's Manual
- Product Type
- PDU
- Mounting Orientation
- Vertical
- Input Voltage
- 230 V AC
- Power Rating (Watt)
- 8600 W
- Form Factors Supported
- Vertical rackmount installation supported with included mounting brackets; supports tooless mounting in button-mount compatible racks
- Network Compatibility
- 10 Mbps; 100 Mbps (Fast Ethernet)
- Reported Load Segments
Reports input current per phase (L1, L2, L3) and output current for each breakered load bank (13.9A balanced max per banks B1-B3); Outlets are color-coded and labeled for phase and load bank identification; L1-L2 feeds black outlets (B1); L2-L3 feeds dark-gray outlets (B2); L3-L1 feeds light-gray outlets (B3)
- Operating Temperature Range
- 32 to 122F (0C to 50C)
- Output Nominal Voltage
- 200; 208; 240
- PDU Form Factor
- Vertical (0U)
- Network Monitoring Port
- RJ45 Network port, RJ45 Config/Console Access port; 2x USB A ports supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules. USB B port (Configuration & Console Access)
- Overload Protection
- 3 20A circuit breakers, one per output load bank
- Frequency Compatibility
- 50 / 60 Hz
- Front Panel LEDs
Set of 6 LEDs identify the value displayed on the large digital display: Amperage (A), Kilowatts (kW), Voltage (V), Unbalance percentage (%UB), Temperature (T), Humidity (%RH); One additional LED for each output load bank (B1-B3) offers information power availability: GREEN (<80% load), YELLOW (>80% load), RED (Power OFF), RED FLASHING (Power OFF/breaker trip)
- Current Measurement Accuracy (Amps)
- +/-1%
- Package Includes
- PDU3VN10G30 10kW 200/208/240V 3-Phase Monitored PDU, 10 ft. cord;(42) C13/C14 plug-lock inserts;(6) C19/C20 plug-lock inserts;Spare mounting buttons;(2) Conventional mounting brackets;Configuration cable for network interface;Button/bracket-mounting hardware;Owner's manual
- Power Measurement Accuracy (Watts)
- +/-1%
- Output Receptacles
- (42) C13; (6) C19
- Output Capacity Details
- 10kW (240V), 9.6kW (230V), 9.1kW (220V), 8.6kW (208V), 8.3kW (200V) total capacity; 13.9A max per breakered outlet bank; 12A max per C13 outlet
- Maximum Input Amps
- 24
- Communications Cable
- RJ45-to-DB9 configuration/console Access cable
- Storage Temperature Range
- -30°C to +60°C (-22°F to +140°F)
- Operating Elevation (ft.)
- 0-10,000
- Input Phase
- 3-Phase
- Material of Construction
- Metal
- Front Panel LCD Display
Large digital display reports Amperage, Kilowatts, Voltage, Unbalance percentage, Temperature* and Humidity* information (*requires ENIVIROSENSE option); Small digital display provides detail on the measurement the large display is reporting: Input-phase (L#), Load bank (B#), Sensor (S#), Load unbalance (UB), Output power (OP)
