- MFR #
- LCR 2400
- Zoro #
- G0460327
- UPC #
- 037332040015
- Country of Origin
- China
- Item
- Power Conditioner
- Max. Amps
- 20 A
- Input Voltage
- 120V
- Output Voltage
- 120V
- Power Rating
- 2.4kVA
- Output Watts
- 2,400 W
- Hardwired/Corded
- Corded
- Phase
- 1
- Voltage Regulation %
- -10, +16%, +9%
- Number of Outlets
- 14
- NEMA Plug Configuration
- 5-15P
- NEMA Receptacle Configuration
- 5-15R
- Mounting Type
- Rack Mount
- Features
- LEDs Display Incoming Voltage Range, Surge Suppression and Line Fault Status
- Standards
- RoHS
- EMI / RFI AC Noise Suppression
- 80 dB
- Brownout Correction
- Input voltages between 111V (+/-3V) and 103V (+/-3V) are boosted by 9%.
- Form Factors Supported
- Standard 19 inch rack mount format using 3 rack spaces (3U).
- Voltage Regulation Description
- Maintains usable 120V nominal voltage during brownouts as low as 89VAC and over-voltages as high as 147VAC. Input voltages between 112Vto127V are passed through unchanged.
- Overvoltage Correction
- Input voltages over 128V (+/-3V) are reduced by 10%
- Severe Brownout Correction
- Input voltages below 102V (+/-3V) are boosted by 19%.
- Output Capacity Details
- Supports 120V 20A 2400W intermittent and 16A 1920W continuously when connected to a 120V 20A rated circuit; Supports 120V 15A 1800W intermittent and 12A 1440W continuously when connected to a 120V 15A rated circuit
- Front Panel LEDs
- 7 LEDs show incoming voltage status, protection present and line fault conditions
- Package Contents
- 2400W Rack Mount Line Conditioner, LCR2400 Line Conditioner, Mounting hardware, Instruction manual
- Product Name
- 2400W Rack Mount Line Conditioner
- Additional Information
Convenient 19 inch rackmount format installs in any 2 or 4 post equipment rack, Voltage Regulation: +10%/-12%, Input voltages over 128V are reduced by 9.6%, Input voltages between 103 and 112V are boosted by 8.9%, Input voltages below 102V are boosted by 18.8%, Network grade AC surge suppression, Two built-in isolated filter banks prevent noise interaction between connected devices, Black color outlets offer basic filtering, white color outlets offer enhanced filtering for the most sensitive connected devicesMaintains regulated output voltage during severe brownouts and overvoltages for computer accessories, printers, home theater equipment, a/v components, sound reinforcement, point-of-sale equipment, and other applications requiring clean, regulated AC power.
- Load Capacity (VA)
- 2400 W
- Protection Type
- EMI / RFI, Surge, Brownout, Over Voltage
- Housing Material
- Steel
- Maximum Current
- 20 A
- Manufacturer Warranty
- 2 yr Limited
- Frequency
- 60 Hz
- Surge Suppression Rating
- 1,440 J
- Voltage Regulation
- 9%; -10%; 19%
- Wiring
- Corded
- Receptacle Configuration
- 5-15R
- Mounting
- Rack
- Plug Configuration
- 5-15P
- Power Rating - Apparent
- 2.4 kVA
