- MFR #
- SK6-6
- Zoro #
- G0834885
- UPC #
- 037332010018
- Country of Origin
- China
- Item
- Power Strip
- Type
- Right Angled
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Light Gray
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 21 (Canada); CAN/CSA-C22.2 No. 269.3 (Canada); cUL Listed; NOM (Mexico); UL 1449; UL 1363; UL Listed; RoHS
- Output Voltage
- 120 V AC
- Number of Outlets
- 8
- Input Voltage
- 120 V AC
- Diagnostic LED Details
- PROTECTION PRESENT (green), GROUNDED (red) and LINE OK (green)
- Outlets Measurement (Center to Center)
- 28.6mm
- UL1449 3rd Edition (AC Suppression)
- UL1449 3rd Edition
- Immunity
- Conforms to IEE 587 / ANSI C62.41
- Circuit Breaker (amps)
- 15
- Material of Construction
- Plastic
- Clamping Voltage (RMS)
- 140
- Output (Watts)
- 1800
- Diagnostic LED(s)
- Yes
- Keyhole Slot Mounting Measurement (Center to Center)
- 114.3mm
- Frequency Compatibility
- 50 / 60 Hz
- AC Suppression Joule Rating
- 1080
- AC Suppression Response Time
- < 1 ns
- AC Suppression Surge Current Rating
- 54,500 amps
- Nominal Input Voltage(s) Supported
- 120V AC
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
- Output Receptacles
- (8) 5-15R
- Integrated Keyhole Mounting Slots
- Yes
- Surge Energy Rating
- 1080 J
- Power Handling
- 1800 VA
- Maximum Surge Current
- 54.5 kA
- Compatibility
- Personal computers, CAD/CAM/CAE workstations, network nodes, fileservers, point-of-sale terminals and audio/visual devices
- Circuit Breaker
- Yes
- Certifications & Standards
- UL1449 (let through rating 330V), IEEE 587 Category A and B, ANSI C62.41, UL1363, cUL
- Package Contents
- 8 Outlet 120V Surge Suppressor, Child Safety Covers, Color-coded cord identifiers, Warranty information and Instruction manual
- Maximum Line Current
- 15 A
- Network (Ethernet) Protection
- No
- Mounting Holes or Slots
- Yes
- Package Includes
- SK6-6 Surge Suppressor;Child Safety Covers;Color-coded cord identifiers;Warranty information and Instruction manual
- Input Plug Features
- Right Angle (36D)
