- MFR #
- TLP1008TELTV
- Zoro #
- G4593565
- UPC #
- 037332119070
- Country of Origin
- China
- Item
- Power Strip
- Type
- Surge, Tel/Modem/Coaxial Protection
- Total Number of Outlets
- 10
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- Approvals RoHS; UL1449/1363/497A/cUL/FCC Part68/Industry Canada
- Medical Grade
- No
- NEMA Plug Configuration
- NEMA 5-15P
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- Max. Amps
- 15A
- Communication Port
- (2) Coaxial, (3) RJ11 Telephone
- NEC Cord Designation
- SJT
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- Number of Outlets
- 10
- For Use With
- DVDs, Protecting TVs, Satellites, Stereos and Other Entertainment Systems
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 10
- Outlet Center Distance
- 28.4mm Standard, 56.8mm Standard and Transformer
- Rated Joules
- 3,330
- Coax Surge Protection
- Yes
- Max. Surge Current
- 13.5 kA
- Circuit Breaker
- 1
- Housing Material
- Plastic
- Number of Transformer Outlets
- 4
- Power Indicator
- Yes
- Voltage
- 120VAC
- Includes
- 6 ft gold coax Cable, 6 ft RJ11 Cable, Instruction Manual and Warranty Information
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Telephone/Fax Surge Protection
- Yes
- NEMA Receptacle Configuration
- NEMA 5-15R
- Color - Ext. Cords and Outlet Strips
- Black
- Mounting Style
- Keyhole
- Hz
- 50/60 Hz
- Noise Attenuation
- Up to 40dB
- Outlet Surge Protection
- Yes
- Number of Outlet Rows
- 2
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Number of Conductors
- 3
- Application
- Home; Office
- Trade Designation
- SJT
- USB Charging Port
- 0
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Input Voltage
- 120 V AC
- Compatibility
- Ideal for protecting TVs, DVDs, satellites, stereos and other entertainment systems
- Maximum Surge Amps
- 135000
- Dataline Protection
- Fax/Modem/Phone
- AC Suppression Joule Rating
- 3345
- Input Cord Details
- SJT
- Frequency Compatibility
- 50 / 60 Hz
- Outlets Measurement (Center to Center)
- Between Standard Outlets = 28.4mm; Between Standard and Transformer Outlets = 56.8mm
- Output Receptacles
- (10) 5-15R
- Package Contents
- TLP1008TELTV 10 Outlets Surge Suppressor, 6-ft. RJ11 cable, 1 set nickel-plated coax connectors, Instruction manual and warranty information
- Material of Construction
- Plastic
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Overload Protection
- 15A resettable circuit breaker
- AC Suppression Response Time
- < 1 ns
- Output Voltage
- 120 V AC
- Circuit Breaker (amps)
- 15
- Mounting Holes or Slots
- Yes
- Certifications & Standards
- UL1449 (Let through rating 330V), UL1363, UL497A, FCC Part 68, cUL, IEEE 587 category A&B specifications
- EMI / RFI Filtering
- Up to 40 dB
- Outlet Safety Covers Detail
- Includes built-in sliding outlet safety covers
- Network (Ethernet) Protection
- No
- Nominal Input Voltage(s) Supported
- 120V AC
- Maximum Line Current
- 15 A
- Cable (Coax) Protection
- Yes
- Outlet Orientation
- Two rows of outlets, including 4 widely spaced for transformers
- Diagnostic LED(s)
- Yes
- Surge Energy Rating
- 3345 J
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Frequency
- 50/60 Hz
- Power Handling
- 1800 VA
- Package Includes
- TLP1008TELTV surge suppressor;6-ft. RJ11 cable;6-ft. (1.83 m) gold coax cable;Instruction manual and warranty information
- Maximum Current
- 15 A
- Product Type
- Surge Protector Outlet Strip
- Maximum Surge Current
- 13.5 kA
- Plug Style
- Right Angle
- Number of Circuit Breakers
- 1
- Rated Energy Absorption
- 3,330 J
- Medical Facility Use UL Rating
- UL 1363
