UPS Type
Line Interactive
Output Voltage
110/115/120V
Backup Time (Half/Full Load)
16.5 min/3 min
Outlet Type
(2) Surge; (6) UPS/Surge
NEMA Plug Configuration
5-15P
NEMA Receptacle Configuration
(8) 5-15R
Transfer Time
6 milliseconds typical (10 milliseconds max)
Switches
Power off/on switch
Front Panel LCD Display
Touchscreen LCD reports input voltage, output voltage, load percentage, battery charge percentage and overload status
Output Voltage Regulation (Battery Mode)
120V (±10%)
Battery Recharge Rate (Included Batteries)
8 hours (10% to 90%)
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Installation Form Factors Supported with Included Accessories
Tower
Output Voltage Regulation (Line Mode)
120V (+6%/-12%)
UPS Certifications
Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
Battery Replacement Description
Replaceable internal batteries (see manual)
Relative Humidity
0 to 90%, non-condensing
Nominal Input Voltage(s) Supported
120V AC
Storage Temperature Range
+5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
Audible Alarm
UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145
UPS Dataline Suppression
1 line TEL/DSL or Ethernet
PowerAlert Software
For local monitoring via the UPS™s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
AC Mode BTU / Hr. (Full Load)
25.3
Output Volt Amp Capacity (VA)
700
Half Load Runtime (min.)
16.5 min. (240w)
Communications Cable
USB and DB9 interface cables included
High Voltage Transfer to Battery Power (Setpoint)
145
Battery Access
Battery access door
Full Load Runtime (min.)
3 min. (480w)
Rated input current (Maximum Load)
10A
Output Watt Capacity (Watts)
480
Low Voltage Transfer to Battery Power (Setpoint)
89
Communications Interface
DB9 Serial; USB (HID enabled)
Input Circuit Breakers
10A
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
EMI / RFI AC Noise Suppression
Yes
Recommended Electrical Service
15A 120V
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
Primary Form Factor
Tower
DC System Voltage (VDC)
12
Overvoltage Correction
Input voltages between 128 and 149 are reduced by 15%
Output AC Waveform (Battery Mode)
PWM sine wave
UPS AC Suppression Joule Rating
316
AC Mode Efficiency Rating (100% Load)
>95%
UPS Certification Details
UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS A; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)
Individually Controllable Load Banks
No
High Availability UPS Features
Battery Independent Restart
Undervoltage Correction
Input voltages between 89 and 108 are boosted by 18%
UPS AC Suppression Response Time
Instantaneous
