VA Rating - UPS Systems
750.0 VA
UPS Type
Line Interactive
Output Voltage
110/115/120V AC
Backup Time (Half/Full Load)
8.3 min/2.2 min
Outlet Type
(3) Surge; (3) UPS/Surge
Includes
USB and Telephone Interconnection Cables
Transfer Time
2 to 4 msec
NEMA Plug Configuration
5-15P
NEMA Receptacle Configuration
(6) 5-15R
Fax/Modem Line Protection
Yes
Special Features
Advanced AVR Corrects Brownouts and Overvoltages, Pure Sine Wave Output
Standards
CSA (Canada), FCC Part 15 Class B (USA), NOM (Mexico), RoHS, UL1778
Automatic Volts Regulation
Yes
Capacity - Batteries
750 VA/450 W
Battery Type
Sealed Lead Acid (SLA)
Operating Temp. Range
122°F (50°C)
Input Connection
6 ft Cord with NEMA 5-15P Plug
EMI / RFI AC Noise Suppression
Yes
Low Voltage Transfer to Battery Power (Setpoint)
89
Battery Replacement Description
Hot-swappable, user replaceable batteries
Rated input current (Maximum Load)
12A
AC Mode BTU / Hr. (Full Load)
38
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
UPS Dataline Suppression
1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
Undervoltage Correction
Input voltages between 89 and 104 are boosted by 14%
Communications Interface
USB (HID enabled)
Internal UPS Replacement Battery Cartridge
RBC51
Output AC Waveform (Battery Mode)
PWM sine wave
UPS AC Suppression Response Time
Instantaneous
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
High Voltage Transfer to Battery Power (Setpoint)
139
Battery Recharge Rate (Included Batteries)
Less than 4.5 hours from 10% to 90%
AC Mode Efficiency Rating (100% Load)
0.97
UPS Certifications
Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
Output Volt Amp Capacity (VA)
750
Installation Form Factors Supported with Optional Accessories
Wallmount ( UPSWM - tower mounting kit)
Battery Access
Battery access door
Nominal Input Voltage(s) Supported
120V AC
Storage Temperature Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity
0 to 95%, non-condensing
Installation Form Factors Supported with Included Accessories
Tower
LED Indicators
4 LEDs indicate line power, battery power, overload and battery low/replace status
Full Load Runtime (min.)
2.2 min. (450w)
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
DC System Voltage (VDC)
12
Alarm Cancel Operation
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
Half Load Runtime (min.)
8.3 min. (225w)
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Primary Form Factor
Tower
UPS AC Suppression Joule Rating
510
Output Watt Capacity (Watts)
450
Switches
2 Switches control off/on power status and alarm-cancel/self-test operation
Audible Alarm
Audible alarm indicates power-failure and low-battery conditions
Output Voltage Regulation (Battery Mode)
+/- 5%
Individually Controllable Load Banks
No
Recommended Electrical Service
15A 120V
Communications Cable
USB interface cable included
Battery Mode BTU / Hr. (Full Load)
512
High Availability UPS Features
Hot swappable batteries
Maximum Operating Temperature
122°F (50°C)
Dataline Protection
RJ-45
Status Indicators
4 LEDs indicate performance conditions: GREEN "online" / GREEN "voltage regulation enabled" / RED "on battery" / YELLOW "battery low/replace"
Battery Chemistry
Valve Regulated Lead Acid
Typical Battery Recharge Time
4 Hour
Additional Information
SMART750USB line-interactive UPS system offers extended voltage regulation (AVR) and battery support as well as complete AC and dialup/DSL/ethernet line surge suppression, Supports entry level PC systems for up to 45 minutes during power failures to enable a safe system shutdown, Supports a max load of 750VA/450 watts for 5 minutes and a half load of 375VA/225 watts for 17 minutes, Automatic Voltage Regulation (AVR) circuits correct brownouts as low as 83 volts without using battery power, Attractive black tower configuration, Includes 3 battery-supported outlets, plus 3 additional surge-only outlets, 6 foot AC line cord (all NEMA 5-15), USB port enables unattended shutdown without data loss during extended power failures; includes USB cable, Built-in USB port supports on battery, low battery, power restored, AC line voltage, DC battery voltage and battery capacity messaging; interface supports timed inverter shutoff after unattended shutdown, activate self-test and 10 second reboot of connected equipment, PowerAlert UPS monitoring and unattended shutdown software available via free download from www.tripplite.com, Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting completely locked computers by automatically switching UPS power off and back on again (part #WATCHDOGSW), Built-in dataline suppression jacks protect a single dialup phone / DSL line or network Ethernet line connection, Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status, 750VA / 450 watt power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment, Supports battery replacement via built-in access panel, Compatible with 120V / 60Hz applications for USA, Canada, Mexico and more, 2 year manufacturer's warranty, $200,000 Ultimate Lifetime Insurance (USA & Canada Only)
Package Contents
SMART750USB Standby UPS System, USB and telephone interconnection cables, Instruction manual with warranty information
Surge Energy Rating
510 J
Load Capacity
750 VA/450 W
Waveform Type
Pulse-width Modulated Sine Wave
Software Included
PowerAlert Software
Output Capacity (Watts)
450
Product Certifications
CSA (Canada); NOM (Mexico); UL 1778
Product Compliance
FCC Part 15 Class B (USA)
UPS Applications
Home/Office Desktop; Retail/Point of Sale; Hospitality
Package Includes
SMART750USB line interactive UPS System;USB and telephone interconnection cables;Instruction manual with warranty information
Output Ports Included
USB
Input Current - Maximum
12 A
Number of Outlets - UPS
6
Surge Suppression Rating
510 J
Automatic Voltage Regulation
Includes Automatic Voltage Regulation
Manufacturer Warranty
2 yr, 3 yr Registration
Audible Alarm Conditions
Low Battery, Power Outage
External Battery Compatible
Not External Battery Pack Compatible
Transfer Time - Minimum
2 msec
Battery Recharge Time
4.5 hr
Run Time - Full Load
2.2 min
Number of Outlets - Surge Only
6
Receptacle Configuration
5-15R
Includes Battery
Battery Included
Power Rating - Real
450 W
Data Line Protection
Includes Data Line Surge Protection
Transfer Time - Maximum
4 msec
Operating Temperature - Minimum
32 Degrees F
Power Rating - Apparent
750 VA
Operating Temperature - Maximum
104 Degrees F
