UPS Type
Line Interactive
Output Voltage
110/115/120V
Backup Time (Half/Full Load)
6 min/2 min
Outlet Type
(2) Surge; (6) UPS/Surge
NEMA Plug Configuration
5-15P
Transfer Time
6 milliseconds typical (10 milliseconds max)
NEMA Receptacle Configuration
(8) 5-15R
UPS Certification Details
UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS A; RETIE (Colombia)
Audible Alarm
UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
Battery Replacement Description
Replaceable internal batteries (see manual)
Nominal Output Voltage(s) Supported
110V; 115V; 120V
AC Mode Efficiency Rating (100% Load)
>95%
Output Watt Capacity (Watts)
900
Output Voltage Regulation (Battery Mode)
120V (±10%)
Nominal Input Voltage(s) Supported
120V AC
Installation Form Factors Supported with Included Accessories
Tower
UPS AC Suppression Joule Rating
316
Rated input current (Maximum Load)
12A
Battery Recharge Rate (Included Batteries)
8 hours (10% to 90%)
Undervoltage Correction
Input voltages between 89 and 108 are boosted by 18%
High Voltage Transfer to Battery Power (Setpoint)
145
Front Panel LCD Display
Touchscreen LCD reports input voltage, output voltage, load percentage, battery charge percentage and overload status
Communications Interface
DB9 Serial; USB (HID enabled)
Low Voltage Transfer to Battery Power (Setpoint)
89
UPS AC Suppression Response Time
Instantaneous
Battery Access
Battery access door
Relative Humidity
0 to 90%, non-condensing
Output Voltage Regulation (Line Mode)
120V (+6%/-12%)
Output Volt Amp Capacity (VA)
1440
Full Load Runtime (min.)
2 min. (900w)
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
Switches
Power off/on switch
Output AC Waveform (Battery Mode)
PWM sine wave
DC System Voltage (VDC)
12
EMI / RFI AC Noise Suppression
Yes
Primary Form Factor
Tower
Storage Temperature Range
+5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Recommended Electrical Service
15A 120V
Overvoltage Correction
Input voltages between 128 and 149 are reduced by 15%
PowerAlert Software
For local monitoring via the UPS™s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145
Communications Cable
USB and Serial interface cables included
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
Half Load Runtime (min.)
6 min. (450w)
UPS Certifications
Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
High Availability UPS Features
Battery Independent Restart
Input Circuit Breakers
15A
Audible Noise
<50dB @ 1m front side
AC Mode BTU / Hr. (Full Load)
14
Individually Controllable Load Banks
No
