- VA Rating - UPS Systems
- 350.0 VA
- Item
- UPS System
- UPS Type
- Standby
- Power Rating
- 350VA
- Mounting
- Desktop/Tower
- Wattage
- 210 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 7 min/2 min
- Outlet Type
- (3) Surge; (3) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 6
- Footnotes
- 4,6
- NEMA Receptacle Configuration
- (6) 5-15R
- Ports
- TEL/DSL, USB
- Special Features
- Cold Start Operation Supported
- Hz
- 60 Hz
- Fax/Modem Line Protection
- Yes
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Automatic Volts Regulation
- No
- Display Type
- No Display
- Includes
- UPS with 6 Outlets
- Phase
- Single
- Input Current
- 12 A
- NEMA Plug Configuration
- 5-15P
- Transfer Time
- 2 to 4 msec
- Standards
- CSA, FCC Part 15 Class A, NOM, RoHS, UL1778
- Capacity - Batteries
- 350 VA/210 W
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- ABS
- Battery Type
- VRLA
- UPS AC Suppression Response Time
- Instantaneous
- Input Phase
- Single-Phase
- EMI / RFI AC Noise Suppression
- Yes
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Switches
- Power switch enables UPS on / off control
- Half Load Runtime (min.)
- 7 minutes (105W)
- UPS Certifications
- Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
- UPS Certification Details
- CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; Meets ISTA 2A Standard
- Hot-Swap PDU options
- PDUB15 (2U / 8 5-15R outlets)
- Full Load Runtime (min.)
- 2 minutes (210W)
- UPS AC Suppression Joule Rating
- 316
- Output Voltage Regulation (Battery Mode)
- 120V±10%
- Rated input current (Maximum Load)
- 5A
- AC Mode BTU / Hr. (Full Load)
- 13.07
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Battery Replacement Description
- Replaceable internal battery (see manual)
- Expandable Runtime
- No
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- Nominal Input Voltage(s) Supported
- 120V AC
- Audible Alarm
- Alarm reports low-battery, fault, overload and replace battery conditions; Alarm remains silent during battery mode operation until low-battery status occurs; See manual for additional alarm notifications
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +45 degrees Celsius
- Communications Interface
- None
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Output Volt Amp Capacity (VA)
- 350
- Battery Access
- Includes bottom panel battery access door
- Relative Humidity
- Up to 90%, non-condensing
- Individually Controllable Load Banks
- No
- Frequency Compatibility Details
- Auto-sensing
- Internal UPS Replacement Battery Cartridge
IMPORTANT BATTERY REPLACEMENT INFORMATION > If your BC350 UPS has no battery access door, please contact a local electronics repair technician to source and install a matching replacement battery; If your BC350 UPS does have a battery replacement door and the original battery inside has a rating of 12V 2.8AH, please contact Tripp Lite for assistance
- LED Indicators
- Single green LED reports Line Power Mode (ON continuous), Battery Backup mode (flashes ON every 10 seconds); See manual for additional LED notifications
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Low Voltage Transfer to Battery Power (Setpoint)
- 95
- AC Mode Efficiency Rating (100% Load)
- >98%
- Primary Form Factor
- Desktop
- High Voltage Transfer to Battery Power (Setpoint)
- 145
- Output Voltage Regulation (Line Mode)
- 120V±20%
- Output Watt Capacity (Watts)
- 210
- DC System Voltage (VDC)
- 12
- Recommended Electrical Service
- 15A 120V
- Additional Information
- Battery Mode: PWM sine wave output 115V +/-5%
- Typical Battery Recharge Time
- 4 Hour
- Form Factor
- Mini Desktop
- Load Capacity
- 350 VA/210 W
- Package Contents
- BC Series BC350 350VA Mini Desktop UPS, BC350 UPS System, Instruction manual with warranty information
- Package Includes
- BC350 120V 350VA 210W Standby UPS with 6 Outlets;Owner's manual
- UPS Applications
- Computer/Peripherals; Retail/Point of Sale; Hospitality
- High Availability UPS Features
- Surge/noise protection
- Product Compliance
- FCC Part 15 Class A (USA)
- Output Capacity (VA)
- 350
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Output Capacity (Watts)
- 210
- Transfer Time - Maximum
- 10 msec
- Power Rating - Apparent
- 350 VA
- Plug Configuration
- 5-15P
- Run Time - Full Load
- 2 min
- Transfer Time - Minimum
- 6 msec
- Audible Alarm Conditions
- Low Battery, Overload, Replace Battery
- Power Rating - Real
- 210 W
- Replacement Battery Part Number
- BC350
- Input Current - Maximum
- 5 A
- Number of Outlets - Surge Only
- 3
- Operating Temperature - Maximum
- 104 Degrees F
- Operating Temperature - Minimum
- 32 Degrees F
- Output Ports Included
- USB
- Number of Outlets - UPS
- 3
- Includes Battery
- Battery Included
- External Battery Compatible
- Not External Battery Pack Compatible
- Receptacle Configuration
- 5-15R
- Visible Indicator Light Conditions
- Battery Low, Fault, Overload, Replace Battery
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Frequency
- 50/60 Hz
- Surge Suppression Rating
- 316 J
- Battery Chemistry
- Valve Regulated Lead Acid
- Manufacturer Warranty
- 2 yr Limited
- Data Line Protection
- No Data Line Surge Protection
