Product Contributes To Reducing Energy Consumption
Fax/Modem Line Protection
No
Hz
60 Hz
NEMA Plug Configuration
5-15P
Includes
6 ft DB9 Serial Monitoring Cable, 6 ft USB Monitoring Cable, SMART700HG 700VA/450W Medical-Grade Tower UPS System
Ports
DB9 Serial, USB
NEMA Receptacle Configuration
(4) 5-15R
Transfer Time
2 to 4 msec
VA Rating - UPS Systems
700.0 VA
Automatic Volts Regulation
Yes
Phase
Single
Display Type
LED
Input Current
5.5 A
Special Features
AVR Corrects Brownouts and Overvoltages, Power Management Software, Pure Sine Wave Output
Standards
CSA (Canada), FCC Part 15 Class a (USA), RoHS, UL 60601-1, UL1778
Voltage
120
Battery Type
Sealed Lead Acid (SLA)
Operating Temp. Range
104°F (40°C)
Capacity - Batteries
700 VA/450 W
Input Connection
6 ft Cord with NEMA 5-15P-HG Plug
Housing Material
PVC
Severe Undervoltage Correction
Input voltages between 81 and 95 are boosted by 21%
Low Voltage Transfer to Battery Power (Setpoint)
81
Leakage Current
Equal to 100 microamps
Network Monitoring Port Description
Supports detailed monitoring of UPS and site power conditions
Output Volt Amp Capacity (VA)
700
Output Voltage Regulation (Battery Mode)
115V (+/- 5%)
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in communication ports , download PowerAlert Local software at http://www.tripplite.com/poweralert
Full Load Runtime (min.)
18 min. (450w)
Relative Humidity
0 to 95%, non-condensing
AC Suppression Joule Rating
480
Output Receptacle Details
Hospital grade output receptacles
AC Mode Efficiency Rating (100% Load)
0.94
Output Voltage Regulation (Line Mode)
-18%, +8%
Individually Controllable Load Banks
No
Rated input current (Maximum Load)
5.5A
AC Suppression Response Time
Instantaneous
Output Isolation Transformer
Hospital grade load isolation transformer
Input Phase
Single-Phase
UPS Certifications
Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to UL1778 (USA); Tested to UL60601-1 (medical grade)
DC System Voltage (VDC)
36
Nominal Input Voltage(s) Supported
120V AC
Alarm Cancel Operation
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
Recommended Electrical Service
15A 120V
Expandable Runtime
No
Audible Alarm
Audible alarm indicates power-failure, overload and low-battery conditions
Primary Form Factor
Tower
Installation Form Factors Supported with Optional Accessories
Wallmount (UPSWM - tower mounting kit)
UPS AC Suppression Joule Rating
480
UPS AC Suppression Response Time
Instantaneous
High Availability UPS Features
Hot swappable batteries
Communications Interface
USB; DB9 Serial
AC Mode BTU / Hr. (Full Load)
97.7
Output AC Waveform (Battery Mode)
PWM sine wave
Overvoltage Correction
Input voltages between 126 and 143 are reduced by 9%
Switches
2 Switches control off/on power status and alarm-cancel/self-test operation
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Output Watt Capacity (Watts)
450
Communications Cable
USB and DB9 serial cabling included
High Voltage Transfer to Battery Power (Setpoint)
143
Nominal Output Voltage(s) Supported
115V; 120V
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 81 to 143
Input Circuit Breakers
10A
Cooling Method
Fan
Battery Replacement Description
Hot-swappable, user replaceable batteries
Battery Access
Battery access door
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
EMI / RFI AC Noise Suppression
Yes
Undervoltage Correction
Input voltages between 96 and 106 are boosted by 10%
Grounding Lug
Grounding lug
Power Factor
0.6
Half Load Runtime (min.)
42 min. (225w)
Battery Mode BTU / Hr. (Full Load)
189.1
Battery Recharge Rate (Included Batteries)
Less than 4 hours from 10% to 90%
LED Indicators
5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Internal UPS Replacement Battery Cartridge
RBC36SLT
Form Factor
Tower
Network Management
SNMP Manageable
USB
Yes
Package Contents
SmartPro 700HG UPS, SMART 700HG Medical Grade UPS System, One USB and One DB9 monitoring cable, Warranty information, Instruction manual
Battery Chemistry
Valve Regulated Lead Acid
Maximum Operating Temperature
104°F (40°C)
Battery Life
6 Year
Load Capacity
700 VA/450 W
Status Indicators
5 front-panel indicator LEDs to show battery charge level, AC line voltage levels, automatic voltage regulation status, UPS load level and replace battery warning
Alarm
Overload, On Battery, Low Battery
Hot Swappable
Yes
Typical Battery Recharge Time
4 Hour
Additional Information
Ideal UPS protection for applications in medical patient-care areas where UL2601-1 listed medical electrical equipment is required, Maintains less than 300 microamps leakage current for UPS and all connected equipment, Built-in isolation transformer with faraday shield offers full isolation and removes common mode noise while maintaining full AC surge suppression in all modes, Line-interactive voltage regulation corrects brownouts and overvoltages from 81 to 143 volts back to usable 120V output levels, without using battery power, Hospital-grade plug and outlets offer added degree of safety and reliability to input/output connections, Full line isolation offers a higher degree of safety and prevents operational problems in sensitive electronic equipment, Resistant to electrostatic discharge, Supports loads up to 700VA / 450 watts, 42 minutes half load runtime (with 350VA load), 18 minutes full load runtime (with 700VA load), 4 protected hospital-grade outlets; 6-ft. cord, RS-232 and USB monitoring ports for remote monitoring and unattended shutdown, SNMP compatible with separate purchase SNMPWEBSOLO ethernet adapter accessory, PowerAlert unattended shutdown software available via free download from www.tripplite.com (cabling included), Complete surge protection, line isolation and EMI/RFI noise filtering, 2 year product warranty, 5 diagnostic LEDs indicate AC present, on battery, voltage correction, overload & battery low/replace, Battery replacement door, Grounding lug
Input Current - Maximum
5.5 A
Number of Outlets - UPS
4
Operating Temperature - Maximum
104 Degrees F
Transfer Time - Maximum
4 msec
Receptacle Configuration
5-15R
Data Line Protection
Includes Data Line Surge Protection
Plug Configuration
5-15P
Includes Battery
Battery Included
Battery Recharge Time
4 hr
Surge Suppression Rating
480 J
Frequency
60 Hz
Power Rating - Apparent
700 VA
Output Ports Included
DB9 Serial, USB
Number of Outlets - Surge Only
4
Transfer Time - Minimum
2 msec
Automatic Voltage Regulation
Includes Automatic Voltage Regulation
Audible Alarm Conditions
Low Battery, Overload
External Battery Compatible
Not External Battery Pack Compatible
Power Rating - Real
450 W
Run Time - Full Load
18 min
Operating Temperature - Minimum
32 Degrees F
Manufacturer Warranty
2 yr
Description
UPS System, Line Interactive, Power Rating 700 VA, Wattage 450 W, Input Voltage 120V AC, Output Voltage 115V AC, 120V AC, Backup Time (Half/Full Load) 42 min/18 min, Mounting Tower/Wall, Outlet Type UPS/Surge, Number of Outlets 4, Medical Grade Medical Grade Approved, NEMA Receptacle Configuration 5-15R, NEMA Plug Configuration 5-15P, Automatic Volts Regulation Yes, Fax/Modem Line Protection No, Transfer Time 2 to 4 msec, Width 8 in, Depth 9 in, Height 13 in, Cord Length 6 ft, Display Type LED
