Tsubaki

Roller Chain, Conveyor, C2102H ANSI, 10 ft.

Tsubaki Roller Chain, Conveyor, C2102H ANSI, 10 ft. C2102HRB
Hover or click to zoom Tap to zoom
  • Roller Chain Item: Roller Chain
  • Roller Chain Type: Heavy Conveyor
  • Industry Chain Size: C2102H
  • Chain Length: 10 ft
  • Chain Material: Carbon Steel
  • Industry Chain Pitch: 2 1/2 in
  • Number of Strands: Single
  • Chain Overall Width: 1.81 in
See full product details
$755.28

Subtotal: $755.28

Tsubaki #C2102HRB Specifications

  • Roller Chain Item: Roller Chain
  • Roller Chain Type: Heavy Conveyor
  • Industry Chain Size: C2102H
  • Chain Length: 10 ft
  • Chain Material: Carbon Steel
  • Industry Chain Pitch: 2 1/2 in
  • Number of Strands: Single
  • Chain Overall Width: 1.81 in
  • Chain Roller Dia.: 1.562 in
  • Roller Bushing Width: 0.75 in
  • Rivet End to Center Line: 0.83 in
  • Pin Type: Riveted
  • Max. Allowable Load: 3,840 lb
  • Item: Roller Chain
  • Outside Pin Dia.: 0.375 in
  • Temp. Range: 15 Degrees to 300 Degrees F
  • Chain Type: Conveyor
  • Tensile Strength: 24,300 lb.
  • Pitch: 2-1/2"
  • Roller Link Plate Height: 1.15 in
  • Length: 10 ft.
  • ANSI Chain Size: C2102H
  • Pin Link Plate Thickness: 0.187 in
  • Includes: (1) Connecting link
  • Standards: American National Standards Institute (ANSI)
  • Connecting End to Center Line: 0.98 in
  • Overall Width: 1.810"
  • Material: Steel
  • Pin Length: 1.81 in
  • Roller Dia.: 1.562"
  • Chain Tensile Strength: 24,300 lb
  • Lubrication: SAE 10 to SAE 50
  • Chain Number: C2102H
  • Features: This Single-Strand Roller Chain is Designed to Help Transfer Motion From One Set of Sprockets to Another
  • Number of Strands (broad rename): Single
  • Working Load Limit: 3,840 lb
  • For Chain Number: C2102H
  • Chain Construction: Riveted Pin
  • Weight Per Length: 3.9 lb/ft
  • Plate Height: 1.16 in
  • Roller Diameter: 1 9/16 in
  • Overall Length: 10 ft
  • Pin Outside Diameter: 0.375 in
  • Pin Contruction: Riveted Pin
  • Number of Links: 48 per 10 ft
  • Inside Width: 0.75 in
  • Minimum Operating Temperature: 15 Degrees F
  • Heavy Series: Yes
  • Pitch Type: Double Pitch
  • Maximum Operating Temperature: 300 Degrees F
  • Series: Double Pitch Conveyor
  • Country of Origin (subject to change): United States

Description

Roller Chain, Chain Construction Riveted Pin, Overall Length 10 ft, Material Steel, Chain Number C2102H, Chain Overall Width 1.823 in, Roller Diameter 1 9/16 in, Tensile Strength 24,300 lbf, Pitch 2 1/2 in, Number of Strands 1, Pin Contruction Riveted Pin, Pitch Type Double Pitch, Inside Width 0.75 in, Series Double Pitch Conveyor, Working Load Limit 3,840 lb, Features This Single-Strand Roller Chain is Designed to Help Transfer Motion From One Set of Sprockets to Another, Heavy Series Yes
