Roller Chain, Heavy Series, 80H ANSI, 10 ft

  • Mfr # 80HRB
  • Zoro # G1371334
product price:
$
440.99
/ea
Free Shipping & Returns

Key Features

Roller Chain Item
Roller Chain
Roller Chain Type
Heavy Riveted
Chain Number
80
Industry Chain Size
80H
Pin Contruction
Riveted
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
80HRB
Zoro #
G1371334
UPC #
-
Country of Origin
Japan

Dimensions

Industry Chain Size
80H
Chain Length
10 ft
Chain Roller Dia.
0.625 in
Overall Length
10 ft
Roller Bushing Width
0.625 in
Length
10 ft
Chain Overall Width
1.543 in
Outside Pin Dia.
0.312 in
ANSI Chain Size
80H
Roller Link Plate Height
0.949 in
Pin Length
1.543 in
Inside Pin Dia.
0.312 in
Roller Dia.
0.625"
Overall Width
1.543"
Pin Link Plate Thickness
0.156 in
Plate Thickness
0.156 in
Inside Width
0.625 in
Roller Diameter
5/8 in
Plate Height
0.819 in, 0.949 in
Pin Hole Diameter
0.312 in
Pin Outside Diameter
0.313 in
Weight Per Length
2.08 lb/ft
Wire Rope Length
10 ft
Fits Chest Size
Heavy Series Chains are Directly Interchangeable With Standard ANSI Chains and Require No Special Equipment Modifications or Sprockets

Details

Roller Chain Item
Roller Chain
Item
Roller Chain
Roller Chain Type
Heavy Riveted
Chain Number
80
Pin Contruction
Riveted
Number of Strands
1
Chain Material
Carbon Steel
Industry Chain Pitch
1 in
Material
Steel
Tensile Strength
17,640 lbf
Series
Heavy
Max. Allowable Load
3,630 lb
Chain Tensile Strength
17,640 lb
Pitch
1 in
Chain Type
Heavy Series
Includes
(1) Connecting Link
Rivet End to Center Line
0.72 in
Standards
ANSI
Temp. Range
15 Degrees to 300 Degrees F
Connecting End to Center Line
0.823 in
Pin Type
Riveted
Lubrication
SAE 10 to SAE 50
Minimum Operating Temperature
15 Degrees F
Chain Construction
Riveted Pin
Working Load Limit
3,630 lb
Resistance Properties
Fatigue Resistance, Wear Resistant
Features
Heavy Series Chains are Directly Interchangeable With Standard ANSI Chains and Require No Special Equipment Modifications or Sprockets
Maximum Operating Temperature
300 Degrees F
Roller Chain Standard
ANSI
Application
Construction, Material Handling
Heavy Series
Yes
Shell Material
Steel

Description

Roller Chain, Chain Construction Riveted Pin, Overall Length 10 ft, Material Steel, Chain Number 80HRB, Chain Overall Width 1.543 in, Roller Diameter 5/8 in, Tensile Strength 17,640 lbf, Pitch 1 in, Application Construction, Material Handling, Number of Strands 1, Pin Contruction Riveted Pin, Inside Width 0.625 in, Series Heavy, Working Load Limit 3,630 lb
