Single Strand Sprocket, Fixed, 35 Chain Size, 3/8 Bore Dia., 9 # of Teeth
Mfr # 35B9F-3/8
Zoro # G2011493
product price:Â $13.59
/eaKey Features
Material
Steel
Number of Teeth
9
Bore Type
Fixed
Bore Dia. (In.)
3/8
Includes
Set Screws
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
35B9F-3/8
Zoro #
G2011493
UPC #
-
Country of Origin
China
Dimensions
Bore Dia. (In.)
3/8
Outside Dia.
1 in
Pitch Dia.
1.097 in
Bore Dia. - Sprockets
3/8 in
Set Screw Size
5/32"
Industry Chain Size
35
Length through Bore
3/4 in
Pitch Dia. (In.)
1.097
Outside Dia. (In.)
1.260
Pitch Diameter
1.097 in
Outside Diameter
1.26 in
Bore Diameter
3/8 in
Tooth Width
0.168 in
Maximum Bore Diameter
3/8 in
Hub Diameter
7/8 in
Description
Single Strand Sprocket, Bore Diameter 3/8 in, For Chain Pitch 3/8 in, For Number of Strands Single, Hub Type One Side, Material Steel, Maximum Bore Diameter 3/8 in, Number of Teeth 9, Outside Diameter 1.26 in, Pitch Diameter 1.097 in, Bore Type Fixed, Chain Number 35, Finish Black Oxide, For Pitch Type Single Pitch, Hub Diameter 7/8 in, Hub Projection 0.582 in, Includes Set Screws, Keyway No, Keyway Depth Not Applicable, Keyway Width Not Applicable, Length through Bore 3/4 in
