  11. Indexable Profiling End Mill, 1-1/4", PHC
Ultra-Dex Usa Indexable Profiling End Mill, 1-1/4", PHC 974-000-021 - main

Indexable Profiling End Mill, 1-1/4", PHC

  • Mfr # 974-000-021

  • Zoro # G8345586

product price: $152.99
/ea
Free Shipping & Returns

Key Features

Overall Length
6"
Depth of Cut
0.0400"
Insert Size
432
Cutting Direction
Left Hand
Shank Dia.
1-1/4"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
974-000-021
Zoro #
G8345586
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
6"
Depth of Cut
0.0400"
Insert Size
432
Shank Dia.
1-1/4"
Shank Length
4.40"
Insert Cutting Edge Length
9.52mm
Shank Width
1-1/4"
Shank Height
1-1/4"
Head Length
1.6000"
Max. Cutting Dia.
1-1/4"
Min. Cutting Dia.
0.7850"

Details

Item
Indexable Turning and Profiling Tool Holder
Cutting Direction
Left Hand
Compatible Hardware
IWSN-433, PB4-CA, PB4-SS, WNMG 432
Side Cutting Edge Angle
15 Degrees
Features
Economical 4 Corner Insert with a Chip Breaker that Enhances Cutting Performance While Maintaining Rigidity, High Feed Design Reduces Radial Cutting Forces and Tool Vibration, Small Cutting Angle Reduces Actual Chip Thickness, End Mill and Face Mill Styles
Number of Coolant Holes
3
Coolant Fed
Non-Coolant Through
Insert Style
WNMG
Insert Shape
80 Degrees Trigon
ANSI Code
DWLNL 20-4D
Cutting Application
Turning
Hardware Included
No
Toolholder Style
DWLNL
Rake
Negative
Insert Holding Type
Pullback Clamp
Insert Inscribed Circle
1/4 in
Insert Clearance Angle
0 Degrees
Side-to-Cutting Tip
1-1/2"
Approach Angle
95 Degrees
Shank Material
Steel
Number of Inserts
3
Max. Speed
655 RPM

Description

Indexable Turning and Profiling Tool Holder, DWLNL, Insert Style WNMG, Overall Length 6 In.
