  11. Indexable Profiling End Mill, 1", PHC
Ultra-Dex Usa Indexable Profiling End Mill, 1", PHC 974-000-088 - main

Indexable Profiling End Mill, 1", PHC

  • Mfr # 974-000-088

  • Zoro # G8344980

product price: $122.99
/ea
Free Shipping & Returns

Key Features

Overall Length
6"
Depth of Cut
0.0400"
Insert Size
432
Cutting Direction
Neutral
Shank Dia.
1"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
974-000-088
Zoro #
G8344980
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
6"
Depth of Cut
0.0400"
Insert Size
432
Shank Dia.
1"
Insert Cutting Edge Length
9.52mm
Shank Length
4.40"
Shank Width
1-1/4"
Head Length
1.6000"
Shank Height
1-1/4"
Max. Cutting Dia.
1"
Min. Cutting Dia.
0.5350"

Details

Item
Indexable Turning and Profiling Tool Holder
Cutting Direction
Neutral
Coolant Fed
Non-Coolant Through
Side Cutting Edge Angle
15 Degrees
Hardware Included
No
Cutting Application
Turning
Features
Economical 4 Corner Insert with a Chip Breaker that Enhances Cutting Performance While Maintaining Rigidity, High Feed Design Reduces Radial Cutting Forces and Tool Vibration, Small Cutting Angle Reduces Actual Chip Thickness, End Mill and Face Mill Styles
Toolholder Style
MCMNN
Compatible Hardware
CL-20, CNMG 432, ICSN-433, NL-46, XNS-48
ANSI Code
MCMNN 20-4D
Number of Coolant Holes
3
Insert Style
CNMG
Insert Shape
80 Degrees Diamond
Insert Inscribed Circle
1/2 in
Insert Clearance Angle
0 Degrees
Approach Angle
50 Degrees
Shank Material
Steel
Insert Holding Type
Clamp and Lock Pin
Rake
Negative
Number of Inserts
3
Max. Speed
655 RPM

Description

Indexable Turning and Profiling Tool Holder, MCMNN, Insert Style CNMG, Overall Length 6 In.

Restrictions

WARNING: Cancer For more information go to www.P65Warnings.ca.gov
