  11. Indexable Profiling End Mill, 3/4", PHC
Ultra-Dex Usa Indexable Profiling End Mill, 3/4", PHC 974-000-010 - main

Indexable Profiling End Mill, 3/4", PHC

  • Mfr # 974-000-010

  • Zoro # G8344825

product price: $179.99
/ea
Free Shipping & Returns

Key Features

Overall Length
4-1/2"
Depth of Cut
0.0320"
Shank Dia.
3/4"
Insert Size
432
Cutting Direction
Right Hand
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
974-000-010
Zoro #
G8344825
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
4-1/2"
Depth of Cut
0.0320"
Shank Dia.
3/4"
Insert Size
432
Shank Length
2.73"
Shank Width
3/4"
Shank Height
3/4"
Head Length
1.7700"
Max. Cutting Dia.
3/4"
Min. Cutting Dia.
0.4110"

Details

Item
Indexable Turning and Profiling Tool Holder
Cutting Direction
Right Hand
Includes
(10) Clamping Screws, (1) Power Screw, (1) Wrench
Coolant Fed
Non-Coolant Through
Insert Shape
55 Degrees Diamond
Compatible Hardware
DNMG 432, IDSN-433, PB4-CA, PB4-SS
ANSI Code
DDJNR 12-4B
Side Cutting Edge Angle
11 Degrees
Number of Coolant Holes
3
Toolholder Style
DDJNR
Features
Economical 4 Corner Insert with a Chip Breaker that Enhances Cutting Performance While Maintaining Rigidity, High Feed Design Reduces Radial Cutting Forces and Tool Vibration, Small Cutting Angle Reduces Actual Chip Thickness, End Mill and Face Mill Styles
Insert Style
DNMG
Coolant Hole Shape
Round
Cutting Application
Turning
Insert Holding Type
Pullback Clamp
Side-to-Cutting Tip
1"
Insert Inscribed Circle
1/2 in
Shank Material
Steel
Insert Clearance Angle
0 Degrees
Approach Angle
93 Degrees
Rake
Negative
Number of Inserts
3
Max. Speed
655 RPM

Description

Indexable Turning and Profiling Tool Holder, DDJNR, Insert Style DNMG, Overall Length 4-1/2 In.
