  11. GP Motor, 1 HP, 1165V RPM, 230/460,145TC
U.S. Motors GP Motor, 1 HP, 1165V RPM, 230/460,145TC HD1P3EC - main

GP Motor, 1 HP, 1165V RPM, 230/460,145TC

  • Mfr # HD1P3EC

  • Zoro # G1942082

product price: $558.99
/ea
Free Shipping & Returns

Key Features

HP
1
Nameplate RPM
1,165
Voltage
230/460V AC
Frame
145TC
Shaft Dia.
7/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HD1P3EC
Zoro #
G1942082
UPC #
786382127220
Country of Origin
Mexico

Dimensions

Shaft Dia.
7/8 in
Shaft Length
2 1/8 in
Manufacturers Warranty Length
3 yr
Length Less Shaft
11 7/8 in
Overall Length
14 in

Details

HP
1
Nameplate RPM
1,165
Voltage
230/460V AC
Frame
145TC
Motor Shaft Rotation
CW/CCW
RPM Range
1,101-1,200
Max. Ambient Temp.
40 Degrees C
Hz
60/50 Hz
Motor Application
General Purpose
Motor Sub Application
Foundries, Mines, Agricultural Fan
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
Motor Thermal Protection
None
Full Load Amps
3.7/1.8 A
Motor Mounting Position
Horizontal
Motor Shaft Design
Keyed
Ins. Class
F
Motor Mounting Type
Rigid Base
Item
General Purpose Motor
Phase
Three
Motor Service Factor
1.15
Voltage Compatibility
200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
No. of Speeds
1
Motor Bearings
Ball
Weight
70 lb
Nominal Efficiency
82.5 %
Includes
All Cast Iron Upgrade, C&D Flanges, Canopy Kits
Standards
CSA Certified, UL Recognized
Motor Frame Material
Cast Iron
Bearing Protection
Double Shielded
Usable @ 208V
Yes
NEMA Design
B
Usable @ 200V
Yes
Removable Base
Regreasable
Inverter Rated
Yes
HP @ 50Hz
1 hp
Duty Cycle
Continuous
Part Winding Start Capable
No
Service Factor @ 50Hz
1.15
RPM @ 50Hz
955
Voltage @ 50Hz
200/400V AC
Inverter Rating
20:1 (3-60hz) Variable Torque, 5:1 (12-60hz) Constant Torque

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1,165, Frame 145TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 3.7/1.8 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 82.5 Percent, 1,101-1,200, CSA Certified, UL Recognized
