Shop U.S. MOTORS

Motor, 1/30HP, 1100/3SPD, 115V, 60HZ, 42Y

  • Mfr # 1374

  • Zoro # G0915395

product price:  $218.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
1,101-1,200
Nameplate RPM
1,100
Voltage
115V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1374
Zoro #
G0915395
UPC #
786382000790
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Body Dia.
5 in
Overall Length
13 21/32 in
Shaft Length
4 in
Length Less Shaft
4 29/32 in
Frame Size
42
Shaft Diameter
1/2 in
Body Diameter
5 in

Details

Item
Fan and Blower Motor
Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
1,101-1,200
Nameplate RPM
1,100
Voltage
115V AC
Frame
42
Motor Mounting Type
Resilient Base
Phase
Single
Motor Enclosure Design
Open Air-Over
Full Load Amps
0.50 A
Hz
60 Hz
Max. Amps
0.8 A
Motor Shaft Rotation
CWLE
Motor Service Factor
0.5
Max. Ambient Temp.
40 Degrees C
Motor Bearings
Self-Align
No. of Speeds
3
Application
Washdown
Ins. Class
B
Motor Application
Washdown
Motor Thermal Protection
Auto
Duty
Continuous
Motor Sub Application
Direct Drive Fan/Blower
Weight
9 lb
Blower Stages
1
Duty Cycle
Continuous
Capacitor Required
Capacitor Included
Sub Application
General Purpose
Frequency
60 Hz
Number of Speeds
3
Product Type
Fan and Blower Motor
Nameplate Service Factor @ 60 Hz
1
Ambient Temperature - Maximum
40 Degrees C
Frame Material
Steel
Drive Type
Direct Drive
Insulation Class
B
Motor Enclosure Type
Open Air Over

Description

Fan and Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/30 hp HP, Nameplate RPM 1,100 RPM, No. of Speeds 3, Voltage 115V AC, 0.50 A Full Load Amps, 42 Frame, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWLE, Motor Enclosure Design Open Air Over, Motor Mounting Type Cradle Base, Motor Frame Material Steel, Shaft Length 4 in, Shaft Dia. 1/2 in
