Shop U.S. MOTORS

Motor, 5 HP, 3450 rpm, 230V, 60 Hz, 56 Hz

  • Mfr # EB384
  • Zoro # G0407791
product price:
$
859.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
HP
5
RPM Range
3450 RPM
Voltage
230V AC
Frame
56HZ
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EB384
Zoro #
G0407791
UPC #
786382106232
Country of Origin
Mexico

Dimensions

Shaft Dia.
7/8 in
Overall Length
15 in
Shaft Length
2 3/8 in
Length Less Shaft
12 5/8 in
Height
9 9/16 in
Shaft Diameter
7/8 in
Frame Size
56
Wire Rope Length
15 in
Length
15 in

Details

Item
Air Compressor Motor
Motor Design
Capacitor-Start
HP
5
RPM Range
3450 RPM
Voltage
230V AC
Frame
56HZ
Motor Thermal Protection
Manual
Motor Enclosure Design
Open Dripproof
Motor Mounting Type
Rigid Base
Standards
CE, CSA, Energy's Efficiency Regulation 10 CFR Section 431 Subpart B, ISO 9001:2015, UL
Motor Bearings
Ball
Motor Shaft Rotation
CCW
Max. Ambient Temp.
40 Degrees C
Capacitor Included
257,50
Motor Application
Pump
Hz
60 Hz
Phase
Single
Duty
CONT
Full Load Amps
21.5 A
Motor Service Factor
1.15
Nameplate RPM
3,450
Ins. Class
F
No. of Speeds
1
Weight
50 lb
Motor Sub Application
Air Compressor
Duty Cycle
Continuous
Max. SF Amps
24.4 A
Usable @ 208V
Not Usable at 208V
Application
Pump
Manufacturers Warranty
243 mo
Frequency
60 Hz
Number of Speeds
1
Full Load Current @ 60 Hz
21.5 A
Ambient Temperature - Maximum
40 Degrees C
Motor Enclosure Type
Open Drip Proof
Insulation Class
F
Product Type
Pump Motor
Bearing Type
Ball
Usable @ 200V
Not Usable at 200V
Service Factor Current
24.4 A
Nameplate Service Factor @ 60 Hz
1.15

Description

Air Compressor Motor, CC Number CC030A, Duty Cycle Continuous, Frame 56HZ, Hz 60 Hz, Full Load Amps 21.5, Height 9 9/16 in, HP 5, Ins. Class F, Length Less Shaft 12 5/8 in, Max. Ambient Temp. 40 Degrees C, Max. SF Amps 24.4, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start, Motor Enclosure Design Open Dripproof
