Drum Pump, 11 gpm, Buna, 44-1/8 in. L

This item is Discontinued.

Versa-Matic Drum Pump, 11 gpm, Buna, 44-1/8 in. L E5PP2R259D-DRUM

Drum Pump, 11 gpm, Buna, 44-1/8 in. L (Discontinued)

Mfr # E5PP2R259D-DRUM
Zoro # G0506731

Get a 10% off coupon

Free 30-day returns

Get 30 days to pay with Net 30

Real support from real people

Specifications

Product Information

MFR #

E5PP2R259D-DRUM

Zoro #

G0506731

UPC #

Country of Origin

United States

Dimensions

For Container Size

55 gal

Overall Length

44 1/8 in

Inlet Size

1/2"

Manufacturers Warranty Length

1 yr.

Suction Tube Length

29 7/16 in

Air Inlet Size

3/8 in FNPT

Air Outlet Size

3/8 in

Height Above Container

13 11/16 in

Bung Connection Dia.

2 in

Details

Item

Air Operated Drum Pump

For Media Type

Ammonia, Ammonium Hydroxide, Antifreeze, Calcium Chloride, Citric Acid, Diesel Fuel, Ethanol, Ethylene Glycol, Formaldehyde, Glycerin, Hydrochloric Acid, Isopropanol, Methanol, Motor Oil, Potassium Hydroxide (50%), Sodium Bicarbonate, Sodium Bisulfate, Sodium Hydroxide, Stoddard Solvent, Sulfuric Acid, Water

Max. Flow Rate

11 gpm

Max. Viscosity

1,000 cps

Diesel Exhaust Fluid Compatible

Wetted Materials

Buna-N, Polypropylene

Includes Suction Tube

Yes

For Use With

Versa-Matic

Discharge Tube Outlet ID

1/2 in

Discharge Tube Outlet OD

1 3/16 in

Max. Flow GPM

Adapter Type

Bung

Max. Air Inlet (PSI)

100

Discharge Tubing Material

Polypropylene

Includes

Air Filter/Regulator

Delivers

1000 CPS

Type

Twin Diaphragm Drum

Metered

Seal Material

Buna-N

Self-Priming

Yes

Adapter Material

Polypropylene

Suction Tube Material

Polypropylene

Thermal Protection

Yes

Compatible Chemicals

Ammonium Hydroxide, Anhydrous Ammonia, Antifreeze (Coolant), Calcium Chloride, Citric Acid 50%, Deionized Water, Diesel Fuel, Ethyl (Ethanol), Ethylene Glycol, Formaldehyde, Formaldehyde 40%, Fresh Water, Glycerin, Hydrochloric/Muriatic Acid (20%), Isopropyl (Isopropanol), Methyl (Methanol), Motor Oil, Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Stoddard Solvent (Mineral Spirits), Sulfuric Acid (to 10%)

Includes Spout

Max. Fluid Temp.

180 Degrees F

Pump Connection OD

1 3/16 in

Not Recommended Chemicals

Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Brake Fluid, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Cyclohexane, Ethyl Acetate, Formic Acid, Gasoline, Heptane, Hexane, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Hydrazine, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Kerosene, Lacquer Thinners, Methyl Chloride, Methyl Ethyl Ketone (MEK), Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint Thinner, Phosphoric Acid (40% Solution), Sodium Bisulfite, Sodium Hypochlorite/Bleach (to 20%), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Toluene, Trichlorethylene (50%), Turpentine, Xylene

Pump Connection Type

FNPT

Housing Material - Pumps

Polypropylene

Variable Speed

Yes

Includes Bung Adapter

Yes

Pump Connection ID

1/2 in

Suction Tube ID

11/16 in

Min. Air Pressure

10 psi

Suction Tube OD

1 1/16 in

Includes Nozzle

Runs Dry

Yes

Power Source

Air

For Container Type

Drum

Includes Discharge Hose

Duty Cycle

Continuous

Discharge Connection Type

FNPT

Max. Air Pressure

100 psi

Noise Level

86 db

Food Grade

Max. Head Pressure

100 psi

Adapter Connection Type

MNPT

Gear Lube

Max. Head - Pumps

231 ft

Explosion Proof

Pump Ratio

1:1

Min. Operating Temp.

32 Degrees F

Description

Air Operated Drum Pump, Max. Air Pressure 100 psi, Spout Connection Size Not Applicable, Suction Tube Material Polypropylene, Self-Priming Yes, Overall Length 44 1/8 in, Explosion Proof No, Discharge Connection Type FNPT, Spout Length Not Applicable, Food Grade No, Thermal Protection Yes, Air Outlet Size 3/8 in, Bung Connection Dia. 2 in, Variable Speed Yes, Includes Discharge Hose No, Noise Level 86 dB, Max. Viscosity 1,000 cps, Adapter Connection Type MNPT, Duty Cycle Continuous
