  11. Indexable Face Mill, 3.937" Cutter Dia, 6 Inserts, 11.00mm Cut Depth, F2260 Series
Walter Indexable Face Mill, 3.937" Cutter Dia, 6 Inserts, 11.00mm Cut Depth, F2260 Series F2260.B.100.Z06.11 - main

Indexable Face Mill, 3.937" Cutter Dia, 6 Inserts, 11.00mm Cut Depth, F2260 Series

  • Mfr # F2260.B.100.Z06.11

  • Zoro # G8250934

product price: $1,796.99
/ea
Free Shipping & Returns

Key Features

Cutter Dia.
3.937"
Series
F2260
Depth of Cut
11.00mm
Number of Inserts
6
Shank Dia. (In.)
1.26
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
F2260.B.100.Z06.11
Zoro #
G8250934
UPC #
-
Country of Origin
China

Dimensions

Cutter Dia.
3.937"
Depth of Cut
11.00mm
Shank Dia. (In.)
1.26
Diameter
3.937"
Overall Length (In.)
1.969
Cutting Length
0.433"
Overall Length
50.00mm
Insert Cutting Edge Length
11.00mm
Max. Cutting Dia.
113.00mm

Details

Item
Indexable Face Mill
Series
F2260
Number of Inserts
6
Bore
1.260"
Cutting Edge Type
Carbide
Left/Right Hand
Right
Material
All ISO
Insert Screw
FS1009 Torx 20
Number of Inserts Required
6
Nomenclature
F2260.B.100.Z06.11
Cutting Application
Face Milling (Roughing)
Features
4 Cutting Edges per Indexable Insert, Tangential Arrangement of Indexable Inserts
ANSI Code
F2260.B.100.Z06.11
Insert Holding Type
Cutter Retaining Screw
ISO Number
F2260.B.100.Z06.11
Standards
ISO 6462-B
Max. Speed
1,200 RPM
Coolant Fed
Non-Coolant Through
Compatible Hardware
FS1009 T20 Clamping Screw
Side Cutting Edge Angle
0 Degrees

Description

Indexable Face Mill, Max. Cutting Dia. 113.00mm, Depth of Cut 11.00mm, ANSI Code F2260.B.100.Z06.11, Compatible Hardware FS1009 T20 Clamping Screw, Coolant Fed Non-Coolant Through, Cutting Application Face Milling (Roughing)
