Walter Rectangle LNKU Carbide LNKU2010DPR-F57T WKP35S - main

Rectangle LNKU Carbide

  • Mfr # LNKU2010DPR-F57T WKP35S

  • Zoro # G8467365

product price: $39.29
/ea
Sold in multiples of 5 for $196.45

Key Features

Insert Style
LNKU
Insert Shape
Rectangle
Insert Size
2010
Insert Material
Carbide
Corner Radius
0.60mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LNKU2010DPR-F57T WKP35S
Zoro #
G8467365
UPC #
-
Country of Origin
Germany

Dimensions

Insert Size
2010
Corner Radius
0.60mm
Nose Radius
0.024"
Insert Thickness
0.413"
Cutting Edge Length
20.00mm
Width
15.00mm
Thickness
0.413 in

Details

Item
Diamond Milling Insert
Insert Style
LNKU
Insert Shape
Rectangle
Insert Material
Carbide
Workpiece Compatibility
Cast Iron (K), Steel (P)
No. of Edges
4
Chip-Breaker
Yes
Non Ferrous (N) Compatibility
No
Stainless (M) Compatibility
No
Grade
WKP35S
Steel (P) Compatibility
Yes
Inscribed Circle
0.5910 in
Mounting Style
Screw Held
Hardened (H) Compatibility
No
ANSI Number
LNKU2010DPR-F57T WKP35S
For Use With
F2265 Heavy-Duty Cutter
Coating
CVD
Super Alloy (S) Compatibility
No
Rake
Negative
Cast Iron (K) Compatibility
Yes
Insert Application
Medium
Cutting Direction
Right Hand
ANSI Code
LNKU2010DPR-F57T WKP35S
ISO Number
LNKU2010DPR-F57T WKP35S
Primary Material Application ISO Code
K, P
Number of Cutting Edges
4
Finish - Machining
TiCN+Al2O3+TiCN
For Toolholder
F2265.B.125.Z06.12, F2265.B.160.Z08.12, F2265.B.200.Z08.20, F2265.B.200.Z10.12, F2265.B.250.Z10.20, F2265.B.250.Z12.12, F2265.B.315.Z12.20, F2265.B.315.Z14.12
Manufacturer Grade
WKP35S
Measurement System
Metric
Shape
Rectangular
Chip-Breaker Style
16 Degrees Chipbreaker Groove
Coating Process
CVD
Clearance Angle
0 Degrees
Insert Holding Type
Screw Held
Hole Type
Double Countersink Hole
Cutting Application
Medium
Primary Material Application
Cast Iron, Steel
Material - Machining
Carbide
Chip-Breaker Code
F57T

Description

Diamond Milling Insert, Inscribed Circle 0.5910 in, Negative
