Shop WALTER

Straight Flute Tap, 5/8"-11, Plug, 4 Flutes, UNC

  • Mfr # AE2236416-UNC5/8

  • Zoro # G2567089

product price:  $160.99
/ea
Free Shipping & Returns

Key Features

Shank Dia.
1/2"
Tap Material
High Speed Steel
Tap Chamfer
Plug
Tap Size
5/8"
Tap Style
Straight Flute
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
AE2236416-UNC5/8
Zoro #
G2567089
UPC #
-
Country of Origin
Germany

Dimensions

Shank Dia.
1/2"
Tap Size
5/8"
Tap Dimension Type
Inch
Overall Length
4-5/16"
Tap Thread Size
5/8"-11
Thread Length
1"
Pitch Diameter Limit
2B
Shank Length
44.30 mm
75% Thread Drill Size
13.60 mm
55% Thread Drill Size
14.20 mm
65% Thread Drill Size
13.90 mm
Square Size
9.14 mm
Thread Size
5/8"-11
Tap Length Standard
DIN
Square Width
9.14 mm
Square Length
9.14 mm
Shank Diameter
12.19 mm
Wire Rope Length
110 mm

Details

Item
Straight Flute Tap
Tap Material
High Speed Steel
Tap Chamfer
Plug
Tap Style
Straight Flute
Number of Flutes
4
Thread Direction
Right Hand
Standards
DIN/ANSI
Number of Pieces
1
Tap Thread Type
UNC
Tap Finish
TiCN
List Number
AE2236416
Cutting Direction - Machining
Right Hand
Series
Paradur Eco Cl
Measurement System
Fractional Inch
Shank Type - Machining
Straight
Powdered Metal Base Material
Cobalt
Primary Material Application ISO Code
K, N, O
Class of Fit
2B
Threads per Inch
11
Thread Standard
UNC
Primary Material Application
Aluminum, Brass, Bronze, Carbon Fiber, Cast Iron, Copper, Fiberglass, Graphite
Tap Shank Standard
ANSI
Spiral Direction
Neutral
Coolant Fed
Non-Coolant Through
Extended Neck
Yes
Thread Limit
H5/H6
Helix Angle
0 Degrees
Shank Type
Straight

Description

Straight Flute Tap, Thread Size 5/8 In.-11, UNC, Modified Bottoming, Overall Length 110 mm, High Speed Steel, TiCN, Right Hand, Thread Length 25 mm, 75 Percent Thread Drill Size 13.60 mm, Thread Limit H5/H6, Class of Fit 2B
