Coupler Body, (F)NPT, 3/8, Brass
- Mfr # 420
- Zoro # G6815724
Key Features
Specifications
Details
- MFR #
- 420
- Zoro #
- G6815724
- UPC #
- -
- Country of Origin
- Germany
- Item
- Quick Connect Air Coupling
- Interchange Type
- Universal
- Material
- Brass
- Coupling Component
- Socket
- Hose Fitting Gender
- Female
- Connection Type
- Threaded
- Finish/Coating
- Brass
- Max. Flow Rate
- 1,274.25 lpm
- Coupling Locking Type
- Sleeve
- Seal Material
- Nitrile
- Includes Valve
- Yes
- Color
- Gold
- Temp. Range
- -40 Degrees to 250 Degrees F
- Application
- Air Tools, General Pneumatics, Construction and Industrial Plants
- For Use With
- Industrial Interchange
- Valve Type
- Poppet
- Max. Working Pressure @ 70 F
- 1,000 psi
- Barbed
- No
- Connection Thread Type
- NPT
- Shell Material
- Brass
Description
The WEATHERHEAD - 420 is a hose coupling with quick-connect mechanism for tool-free connection and disconnection of hoses in pneumatic and fluid line systems. It features a brass construction with a gold finish and includes a poppet valve integrated into the coupling to control fluid or air flow. The fitting is compatible with industrial interchange standards and is intended for use in pneumatic and fluid line systems used in industrial applications. It is rated for operation at ambient and fluid temperatures from -40°F to 250°F and forms a sealed connection when properly installed with compatible mating components with a maximum working pressure of 1,000 psi.
Key Features:
- Material: Brass body with brass finish for durability.
- Size: 3/8 in hose fitting with 3/8"-18 thread size and matching coupling size.
- Connection type: Female hose fitting with NPT threads.
- Coupling component: Socket with sleeve locking type for secure attachment.
- Valve: Includes a poppet valve for flow control.
- Maximum flow rate: 1,274.25 liters per minute.
- Maximum outside diameter: 7/8 in and overall length of 2 3/8 in.
- Seal material: Nitrile.
- Interchange type: Universal compatibility with industrial interchange fittings.
