Shop WEIDMULLER

300V 10A Terminal And Contact Block, 1784180000

  • Mfr # 1784180000

  • Zoro # G708238139

product price:
$
385.99
/pk 50, $7.72/ea
Free Shipping & Returns

Key Features

Mounting Type
clip-on
Current
24 A
Maximum Voltage
300 V
Termination Style
Screw
For Minimum Wire Size
AWG 26
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1784180000
Zoro #
G708238139
UPC #
-
Country of Origin
Unknown

Dimensions

For Minimum Wire Size
AWG 26
For Maximum Wire Size
AWG 12
Blade Size
0.6 x 3.5 mm
Height (inches)
3.248 inch
Current size C (CSA)
10A
Stripping length
7 mm
Overall Width
0.244 inch
Overall Depth
1.909 inch

Details

Mounting Type
clip-on
Current
24 A
Maximum Voltage
300 V
Termination Style
Screw
Material
Wemid
Standards
IEC 60947-7-1, UL E60693
Wire connection cross-section, finely stranded, min.
0.5 mm²
Wire cross section min. (CSA)
26 AWG
Wire connection cross section AWG, min.
AWG 26
Connection direction
on side
Open sides
right
Connection cross-section, stranded, max.
4 mm²
PE function
No
Wire connection cross section, finely stranded with wire-end ferrules DIN 46228/1, 2 clampable wires, max.
1 mm²
Wire connection cross section AWG, max.
AWG 12
Version
Screw connection, One end without connector
Number of connections
6
Rail
TS 35
Volume resistance according to IEC 60947-7-x
3.99 mΩ
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min.
0.5 mm²
Tightening torque, max.
0.6 Nm
Number of potentials per tier
1
Wire connection cross section, finely stranded, max.
4 mm²
Approvals
CE, CSA, EAC, GERMLLOYD, UR
UL 94 flammability rating
V-0
Wire cross-section, finely stranded, two clampable wires, max.
1 mm²
Tightening torque, min.
0.4 Nm
Continuous operating temp., min.
-50 °C
Continuous operating temp., max.
120 °C
Wire connection cross-section, solid core, min.
0.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max.
2.5 mm²
Torque level with DMS electric screwdriver
1
Gauge to IEC 60947-1
A3
Number of clamping points per level
2
Power loss in accordance with IEC 60947-7-x
0.77 W
Storage temperature, max.
40 °C
Connection cross-section, stranded, min.
0.5 mm²
Wire connection cross section, finely stranded, two clampable wires, min.
0.5 mm²
Wire connection cross-section, solid core, max.
4 mm²
Storage temperature, min.
10 °C
Conductor cross-section, flexible plus plastic collar DIN 46228/1, further connection, max.
2.5 mm²
Number of similar terminals
1
Certificate No. (CSA)
12400-134
Rated impulse withstand voltage
4 kV
Clamping screw
M 2.5
Clamping range, max.
4 mm²
Number of Levels
3
Rated cross-section
2.5 mm²
Number of potentials
3
Rated current
24 A
Wire connection cross section, finely stranded with wire-end ferrules DIN 46228/1, 2 clampable wires, min.
0.5 mm²
End cover plate required
Yes
Pollution severity
3
PE connection
No
Clamping range, min.
0.13 mm²
Storage temperature
10°C...40°C

Description

W-Series, Initiator/actuator terminal, Rated cross-section: 2.5 mm2, Screw connection
