Barrier Strip Terminal Block, 17.5A, 2 Row(S), 2 Deck(S)

This item is Discontinued.

Weidmuller Barrier Strip Terminal Block, 17.5A, 2 Row(S), 2 Deck(S) 1973300000

Barrier Strip Terminal Block, 17.5A, 2 Row(S), 2 Deck(S) (Discontinued)

Mfr # 1973300000
Zoro # G905797712

Get a 10% off coupon

Free 30-day returns

Get 30 days to pay with Net 30

Real support from real people

Specifications

Product Information

MFR #

1973300000

Zoro #

G905797712

UPC #

Country of Origin

China

Dimensions

Solder pin dimensions

d = 1.0 mm, Octagonal

Solder eyelet hole diameter tolerance (D)

+ 0,1 mm

VPE length

25 mm

Height of lowest version

22.7 mm

Width (inches)

1.309 inch

Solder pin length tolerance

+0,02 / -0,02 mm

Solder eyelet hole diameter (D)

1.2 mm

Solder pin length (l)

3.2 mm

VPE height

260 mm

Height (inches)

1.02 inch

Depth (inches)

0.862 inch

VPE width

180 mm

Solder pin dimensions = d tolerance

0 / -0,03 mm

Details

Number of Poles

Number of Rows

Colour chart (similar)

RAL 2000

Insulating material

PA GF

Touch-safe protection acc. to DIN VDE 57 106

Safe from finger touch

Mounting onto the PCB

THT solder connection

Rated current (Use group B / UL 1059)

10 A

Rated impulse voltage for surge voltage class/ contamination degree III/3

2.5 kV

Volume resistance

6.00 mΩ

Insulating material group

Operating temperature, min.

-50 °C

L1 in inches

0.75 inch

Rated impulse voltage for surge voltage class/ pollution degree III/2

2.5 kV

Operating temperature, max.

120 °C

Plugging force/pole, max.

8 N

Rated voltage for surge voltage class / pollution degree III/2

160 V

Type of connection

Board connection

Rated voltage (Use group B / CSA)

300 V

Colour

orange

Institute (CSA)

CSA

Rated current, max. number of poles (Tu=20°C)

13.9 A

Pin series quantity

UL File Number Search

E60693

Certificate No. (cURus)

E60693

Rated current, min. number of poles (Tu=40°C)

17 A

UL 94 flammability rating

V-0

Outgoing elbow

90°

Touch-safe protection acc. to DIN VDE 0470

IP 20

Institute (cURus)

cURus

Temperature range, installation, max.

120 °C

Certificate No. (CSA)

200039-1121690

Pulling force/pole, max.

5.5 N

Approvals

CSA, cURus, EAC

Pitch in inches (P)

0.15 inch

Rated voltage for surge voltage class / pollution degree II/2

320 V

Rated current, min. number of poles (Tu=20°C)

17.5 A

Rated voltage for surge voltage class / pollution degree III/3

160 V

Insulation strength

≥108 Ω

Rated current (Use group B / CSA)

11 A

Contact surface

tinned

Storage temperature, max.

55 °C

Rated voltage (Use group B / UL 1059)

300 V

tested acc. to standard

IEC 60664-1, IEC 61984

Contact material

Copper alloy

Tolerance of solder pin position

± 0.1 mm

Rated current (Use group D / UL 1059)

10 A

Temperature range, installation, min.

-25 °C

Plugging cycles

Rated current, max. number of poles (Tu=40°C)

12.3 A

Storage temperature, min.

-25 °C

Comparative Tracking Index (CTI)

≥550

Rated impulse voltage for surge voltage class/ pollution degree II/2

2.5 kV

Short-time withstand current resistance

3 x 1s with 76 A

Max. relative humidity during storage

80 %

Rated voltage (Use group D / UL 1059)

300 V

Number of solder pins per pole

GWFI

960 °C
